Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 410 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Plinth base height | 40 mm | |
| Sliding door compartment width | 750 mm | |
| Open shelving section width | 450 mm | |
| Upper open shelf internal height | 180 mm | |
| Lower open shelf internal height | 160 mm | |
| Storage compartment internal depth | 540 mm | |
| Vertical fluted trim height on door | 50 mm | |
| Side panel thickness | 18 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total distributed static load capacity | 110 kg | |
|---|---|---|
| Enclosed storage compartment capacity | 0.12 cbm | |
| Recommended maximum user weight for tabletop seating | 0 kg | |
| Sliding door cycle rating | 10000 open/close cycles | |
| Surface finish abrasion resistance | 2000 revolutions | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18mm MDF/particleboard core | |
|---|---|---|
| Tabletop finish | Walnut wood grain melamine veneer | |
| Side and interior panels | Dark charcoal matte laminated engineered wood | |
| Sliding door front panel | Walnut grain laminated panel with vertical fluted MDF trim | |
| Sliding door hardware | Cold-rolled steel sliding rails | |
| Plinth base frame | Dark gray powder-coated engineered wood trim | |
| Shelf panels | 18mm dark matte laminated particleboard | |
| Edge banding | PVC edge trim on all exposed panel edges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Left-side enclosed storage | Sliding door rolls horizontally on metal rails to access hidden interior space | |
|---|---|---|
| Right-side two-tier open shelving | Two fixed horizontal shelves provide readily accessible display and storage | |
| Surface use functionality | Flat level tabletop supports serving ware, reading materials, and decorative objects | |
| Floor clearance | 0 mm flush plinth design sits directly on floor surface | |
| Cleaning accessibility | Smooth laminated surfaces wipe clean with dry or lightly dampened cloth | |
| Assembly configuration | Knock-down flat-pack assembly with cam-lock connectors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room lounge placement | Positioned in front of 3seater sofas for beverage, reading material, and remote storage | |
|---|---|---|
| Small apartment use | Compact 1200mm length footprint fits limited floor space while providing hidden and open storage | |
| Office reception lounge use | Placed in guest waiting areas to hold magazines, cups, and reception decor | |
| Recommended pairing | Matches walnut and dark charcoal case goods, sofas, and media units in modern, minimalist interiors | |
| Prohibited use case | Not suitable as a television stand, dining table, or standing work surface |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for residential tables, applicable for structural performance validation | |
|---|---|---|
| EN 15187:2006 | Surface resistance to cold liquids test for furniture finishes, applicable for household spill resistance checks |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel strength and dimensional tolerance checks | |
|---|---|---|
| GB/T 4893.1-2021 | Surface wear resistance test method for furniture finishes, applicable for tabletop durability verification | |
| GB 18584-2001 | Formaldehyde emission limits for wooden interior decoration materials, applicable for panel safety screening |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel strength and dimensional tolerance checks; 2. GB/T 4893.1-2021: Surface wear resistance test method for furniture finishes, applicable for tabletop durability verification; 3. GB 18584-2001: Formaldehyde emission limits for wooden interior decoration materials, applicable for panel safety screening; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
