Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1800 × 900 × 762 mm | |
|---|---|---|
| tabletop thickness | 12 mm | |
| leg section dimension | 30 x 30 mm | |
| leg wall thickness | 1.2 mm | |
| perimeter frame width | 20 mm | |
| under-table knee clearance height | 720 mm | |
| under-table leg room depth | 840 mm | |
| floor pad diameter | 25 mm | |
| long side edge overhang | 20 mm | |
| short side edge overhang | 20 mm | |
| leg spacing (long side) | 1740 mm | |
| leg spacing (short side) | 840 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| total static distributed load capacity | 200 kg | |
|---|---|---|
| per-leg static load rating | 150 kg | |
| maximum seating capacity | 8 people | |
| table net weight | 65 kg | |
| surface heat resistance | 180 °C | |
| surface abrasion resistance | ≥2000 cycles | |
| frame corrosion resistance | Grade 1 for indoor use | |
| adjustable foot leveling range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop core | 12mm sintered stone with white marble grey veining | |
|---|---|---|
| tabletop edge finish | Matte polished straight cut, no bevel | |
| perimeter support frame | Matte black powder-coated carbon steel | |
| support legs | Square-section matte black powder-coated carbon steel | |
| floor contact pads | Non-slip TPE rubber anti-scratch pads | |
| leg adjustment feet | Injection-molded nylon threaded adjustable feet | |
| assembly hardware | Zinc-plated steel hex bolts and lock washers | |
| surface coating thickness (metal) | 60 μm | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Leveling adjustment | Threaded feet rotate to adjust leg height up to 10mm to stabilize on uneven floors | |
|---|---|---|
| Surface cleaning | Non-porous sintered surface wipes clean with damp cloth, no sealing required | |
| Floor protection | Rubber foot pads prevent hard metal legs from scratching tile, wood or carpet floors | |
| Assembly requirement | Knock-down flat pack assembly, legs bolt to pre-drilled frame mounts | |
| Heat resistance function | Tabletop supports direct placement of hot cookware up to 180°C without surface damage | |
| Under-table access | Fully open unobstructed under-table space with no modesty panel or cross braces, maximizes leg room | |
| Multi-use adaptability | Flat rigid top suitable for dining, home office work, or meeting room use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Fits open-plan modern dining areas, seats up to 8 people for family meals | |
|---|---|---|
| Small apartment kitchen nook | Slim profile and open leg base creates visual lightness for compact spaces | |
| Home office workspace | Flat rigid top supports monitors and office equipment at standard work height | |
| Casual meeting breakout area | Durable easy-clean surface suitable for office pantry or collaborative spaces | |
| Rental property furnishing | Neutral black and white color scheme matches wide range of decor styles | |
| Cafe and bistro seating | Stable steel frame and stain-resistant top suit high-turnover commercial dining |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 15372:2008 | Furniture - Requirements for surface durability of work and dining surfaces | |
| EN 1022:2018 | Furniture - Seating and table stability test methods |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability testing | |
|---|---|---|
| GB/T 4893.4-2013 | Surface wear resistance test for furniture hard surfaces, applicable for tabletop finish verification | |
| GB/T 10357.1-2013 | Table static load and stability test methods, applicable for frame and leg load verification | |
| GB 18584-2001 | Limit of harmful substances for indoor furniture, applicable for emission testing of assembly adhesives |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability testing; 2. GB/T 4893.4-2013: Surface wear resistance test for furniture hard surfaces, applicable for tabletop finish verification; 3. GB/T 10357.1-2013: Table static load and stability test methods, applicable for frame and leg load verification; 4. GB 18584-2001: Limit of harmful substances for indoor furniture, applicable for emission testing of assembly adhesives; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
