Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 900 x 490 mm | |
|---|---|---|
| Tabletop diameter | 900 mm | |
| Tabletop thickness | 25 mm | |
| Drum body height | 350 mm | |
| Under-table floor clearance | 140 mm | |
| Metal leg outer diameter | 38 mm | |
| Leg wall thickness | 1.5 mm | |
| Edge trim width | 10 mm | |
| Floor glide diameter | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load capacity | 100 kg | |
|---|---|---|
| Product net weight | 25 kg | |
| Single leg vertical static load rating | 30 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Recommended maximum number of users | 4 | |
| Floor glide static load rating per unit | 10 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 18mm thick MDF substrate | |
|---|---|---|
| Tabletop surface finish | Matte light beige lacquer coating | |
| Drum body panel | 15mm thick MDF with wrapped matte finish | |
| Support legs | Powder-coated black carbon steel tubing | |
| Edge rim trim | Thin polished dark metal band | |
| Floor protection glides | Injection-molded polypropylene non-scratch feet | |
| Assembly hardware | Zinc-plated steel screw and dowel connectors | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Static fixed-height design | No height adjustment, fixed lounge use height | |
|---|---|---|
| Raised edge anti-slip rim | 10mm tall perimeter lip prevents small item fall | |
| Elevated under-table clearance | 140mm gap allows robotic vacuum access | |
| Knock-down assembly design | Legs attach to drum body via included hardware | |
| Floor protection function | Plastic glides prevent hard floor scratches | |
| Leveling adjustment | 2mm height adjustment range per glide for uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Centered in front of sofa for drinks, decor and magazine placement | |
|---|---|---|
| Small apartment lounge | Compact 900mm diameter fits tight seating areas without blocking walkways | |
| Office reception lounge | Used in waiting areas for guest refreshments and decorative display | |
| Modern minimalist interior schemes | Matte light finish and thin dark legs match contemporary decor styles | |
| Pairing with matching side tables | Coordinated with adjacent C-frame side table for cohesive lounge setups |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable for design reference | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface finishes, applicable for coating performance checks |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for tabletop and body acceptance | |
|---|---|---|
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture finishes, applicable for top finish | |
| GB/T 10357.1-2013 | Table mechanical strength test standard, applicable for static load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for tabletop and body acceptance; 2. GB/T 4893.8-2013: Surface wear resistance test method for furniture finishes, applicable for top finish; 3. GB/T 10357.1-2013: Table mechanical strength test standard, applicable for static load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
