Automatic mm / inch conversion · Core engineering specifications
| Overall nested dimensions (large table outer envelope) | 800 x 800 x 450 mm | |
|---|---|---|
| Large tabletop diameter | 800 mm | |
| Large table total height | 450 mm | |
| Small tabletop diameter | 650 mm | |
| Small table total height | 400 mm | |
| Tabletop thickness | 18 mm | |
| Large table lower ring base diameter | 760 mm | |
| Small table lower ring base diameter | 610 mm | |
| Vertical support leg cross-section | 20 x 20 mm | |
| Metal tube wall thickness | 1.2 mm | |
| Base ring tube diameter | 25 mm | |
| Floor clearance under lower base ring | 20 mm | |
| Edge overhang from frame to tabletop edge | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Large table distributed static load capacity | 100 kg | |
|---|---|---|
| Tabletop surface abrasion resistance | 2000 cycles | |
| Tabletop heat resistance temperature | 120 °C | |
| Frame static stability lateral load | 30 kg | |
| Total set net weight | 24 kg | |
| Surface water resistance rating | IPX4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large tabletop | High-density MDF core with white marble-veined laminate top layer | |
|---|---|---|
| Small tabletop | High-density MDF core with black marble-veined high-gloss laminate top layer | |
| Table edge trim | Matching black PVC edge banding with rounded profile | |
| Frame support legs | Powder-coated carbon steel square tubing | |
| Lower circular base rings | Powder-coated carbon steel round tubing | |
| Frame connection hardware | Zinc-plated steel bolt and bracket fasteners | |
| Floor protection pads | 3 mm thick non-slip EVA rubber pads | |
| Frame surface finish | Matte black electrostatic powder coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Space-saving nesting operation | Small table slides fully partially under large table to reduce footprint when not in use | |
|---|---|---|
| Independent use function | Both tables can be separated and used as standalone accent surfaces | |
| Fixed non-adjustable structure | All frame components are rigidly assembled with no height adjustment, folding, or moving parts | |
| Wipe-clean surface maintenance | Smooth non-porous tabletop allows cleaning with damp cloth without staining | |
| Scratch-resistant tabletop protection | Hard laminate surface resists scuffs from everyday objects like mugs, books, and decor | |
| Floor protection function | Integrated rubber foot pads prevent hard metal contact with hard flooring surfaces | |
| Level installation capability | Minor height adjustment via integrated foot pads to compensate for uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room sofa front placement | Positioned in front of sofas or sectionals to hold drinks, books, remote controls, and decor | |
|---|---|---|
| Small apartment space optimization | Nesting design allows compact storage for small living areas or studio apartments | |
| Office lounge/reception use | Used in reception areas or breakout spaces for guest refreshments and reading materials | |
| Flexible multi-surface hosting | Separated tables provide additional surface area for parties or gatherings when extra display space is needed | |
| Modern minimalist interior schemes | Black and white marble-veined finish pairs with contemporary, industrial, or Scandinavian decor styles |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic tables, applicable to home living room use | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating stability test, applicable to table stability evaluation | |
| EN 13722:2004 | Performance requirements for metal furniture frames, applicable to powder-coated steel structure |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF core tabletop components | |
|---|---|---|
| GB/T 24821-2009 | Performance requirements for metal furniture, applicable to steel frame structure | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to MDF core material | |
| GB/T 4893.8-2013 | Surface abrasion resistance test method for furniture surfaces, applicable to tabletop finish |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF core tabletop components; 2. GB/T 24821-2009: Performance requirements for metal furniture, applicable to steel frame structure; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to MDF core material; 4. GB/T 4893.8-2013: Surface abrasion resistance test method for furniture surfaces, applicable to tabletop finish; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
