Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 800 × 470 mm | |
|---|---|---|
| Overall nested footprint | 1250 x 800 x 470 mm | |
| Large table diameter | 800 mm | |
| Large table height | 470 mm | |
| Small table diameter | 650 mm | |
| Small table height | 450 mm | |
| Tabletop thickness | 15 mm | |
| Base wall thickness | 15 mm | |
| Base cutout nesting clearance | 100 mm | |
| Floor contact pad diameter | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Large table distributed static load capacity | 100 kg | |
|---|---|---|
| Total set net weight | 32 kg | |
| Stone top surface abrasion resistance | 6000 revolutions | |
| Metal base corrosion resistance | 48 hours neutral salt spray | |
| Recommended maximum supported item height | 350 mm | |
| Standard limited warranty period | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Large tabletop | Polished natural black stone with white and gold veining | |
|---|---|---|
| Small tabletop | Polished natural black stone with white and gold veining | |
| Large table base | Brushed brass-finished cold-rolled steel semi-cylindrical drum | |
| Small table base | Brushed brass-finished cold-rolled steel semi-cylindrical drum | |
| Tabletop edge finish | Machine-polished rounded bullnose edge | |
| Base-to-top connector | M8 steel threaded inserts with lock washers | |
| Floor protection glides | Non-marking rubber-padded steel glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Space-saving nesting design | Small table tucks partially under the large table via base cutout | |
|---|---|---|
| Independent use capability | Both tables can be separated and used as standalone accent surfaces | |
| Scratch-resistant table surface | Polished stone top resists minor abrasion and liquid staining | |
| Level adjustment | Base-mounted glides adjust up to 5 mm to level on uneven floors | |
| No assembly required structural base | Drum bases are fully welded as single units, only top attachment needed | |
| Surface cleaning compatibility | Smooth non-porous polished top wipes clean with soft damp cloth | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary use space | Modern residential living rooms in front of sofas and sectionals | |
|---|---|---|
| Secondary use | Luxury apartment lounge areas, boutique hotel reception seating zones | |
| Target users | Urban homeowners and interior designers seeking space-saving statement furniture | |
| Recommended complementary furniture | Low-profile fabric or leather sofas, neutral-toned area rugs | |
| Placement recommendation | Position on hard flooring or low-pile carpet to avoid obstructing nesting movement | |
| Prohibited use case | Outdoor placement or commercial high-traffic dining/work surfaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic tables | |
|---|---|---|
| EN 15185:2010 | Furniture - Test methods for surface resistance to abrasion |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for hardware and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for hardware and structural acceptance; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
