Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 950 x 950 x 460 mm | |
|---|---|---|
| Tabletop thickness | 18 mm | |
| Lower glass shelf thickness | 8 mm | |
| Frame tubular steel diameter | 25 mm | |
| Frame tube wall thickness | 1.2 mm | |
| Lower shelf clearance from floor | 100 mm | |
| Vertical clearance between top and lower shelf | 270 mm | |
| Perimeter base frame width | 30 mm | |
| Diagonal X-brace tube diameter | 16 mm | |
| Lower shelf usable surface dimensions | 780 x 780 mm | |
| Floor contact foot pad diameter | 20 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Net weight | 22.7 kg | |
|---|---|---|
| Tabletop distributed static load capacity | 145 kg | |
| Recommended maximum number of users | 4 | |
| Powder coat finish abrasion resistance | 2000 cycles | |
| Tabletop surface water resistance rating | Level 4 | |
| Warranty period for structural components | 90 days | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 18mm matte white engineered stone/laminate board, scratch and stain resistant | |
|---|---|---|
| Structural frame | Matte black powder-coated carbon steel tubing | |
| Lower storage shelf | 8mm clear tempered safety glass | |
| X-brace supports | 16mm powder-coated steel diagonal bracing on all four sides | |
| Perimeter base frame | Rectangular section steel floor rest with integrated protective foot pads | |
| Fasteners and connectors | Zinc-plated steel hex bolts with lock washers | |
| Floor protection pads | Non-marking TPE plastic feet at all base corners | |
| Frame surface finish | Satin matte black powder coating, 60um thick | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Open lower shelf storage | Cantilevered glass shelf holds books, decor and small items within frame perimeter | |
|---|---|---|
| Frame stability reinforcement | Four-side X-bracing eliminates racking during regular use | |
| Flat-pack assembly | Bolted construction with included hex key, no special tools required | |
| Leveling adjustment | Small adjustable foot pads at base corners compensate for uneven floor surfaces | |
| Surface usability | Smooth non-porous tabletop supports drinks, books and decorative display items | |
| Edge protection | Tabletop sits flush with steel top frame to prevent sharp exposed edges | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living rooms | Positioned in front of sofas and sectionals for drinks, decor and media accessory storage | |
|---|---|---|
| Modern industrial loft interiors | Matches black metal and neutral surface palettes for contemporary industrial decor schemes | |
| Small apartment living spaces | Compact square footprint fits limited seating areas without occupying excess floor space | |
| Office reception lounge areas | Used alongside lounge seating for guest beverage and reading material placement | |
| Studio open-plan living zones | Multi-use surface for casual dining, remote work setup, or decorative display | |
| Showroom home display sets | Paired with matching industrial style seating to stage modern living room vignettes |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Applies to safety, strength and durability requirements for domestic living room tables | |
|---|---|---|
| EN 10346:2015 | Applies to specification for continuous hot-dip coated steel flat products for furniture framing |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden furniture used in residential settings | |
|---|---|---|
| GB/T 4897.3-2015 | Applies to performance requirements for particleboard used in furniture construction | |
| GB 15763.2-2005 | Applies to safety requirements for tempered glass used in furniture components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden furniture used in residential settings; 2. GB/T 4897.3-2015: Applies to performance requirements for particleboard used in furniture construction; 3. GB 15763.2-2005: Applies to safety requirements for tempered glass used in furniture components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
