Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1300 × 700 × 450 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 100 kg | |
|---|---|---|
| Product net weight | 42 kg | |
| Surface scratch resistance | 6 Mohs | |
| Surface heat resistance | 180 °C | |
| Base stability tilt load | 30 kg | |
| Recommended number of users | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | 12mm polished white sintered stone with grey marble veining | |
|---|---|---|
| Tabletop edge trim | Matte black PVC edge banding | |
| Vertical support legs | 2mm thick matte black powder-coated carbon steel | |
| Base cross frame | 2mm thick matte black powder-coated carbon steel | |
| Frame foot pads | 8mm thick non-slip rubber | |
| Frame weld points | Fully ground and powder-coated seamless welds | |
| Surface finish on metal | Matte black textured powder coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Tabletop usage | Flat oval surface supporting drinks, decor and reading materials for living room seating areas | |
|---|---|---|
| Under-table storage clearance | 120 mm floor gap allowing robot vacuum access and slim item storage | |
| Floor protection | Rubber foot pads preventing floor scratches and absorbing minor unevenness | |
| Surface maintenance | Non-porous sintered stone top allowing wipe-clean of spills without staining | |
| Assembly requirement | Knock-down construction connecting tabletop to base with included hardware | |
| Stability design | Wide X-shaped base lowering center of gravity to prevent tipping during regular use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Shipping carton dimensions | 1380 x 780 x 180 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room | Placed in front of 3-seat sofas for daily leisure, drink placement and decor display | |
|---|---|---|
| Apartment lounge areas | Low-profile oval design suitable for compact open-plan living spaces without sharp corners | |
| Modern office reception areas | Neutral black and white finish fits minimalist office waiting areas for guest refreshment service | |
| Show home staging | Contemporary geometric base complements modern interior design schemes for property display | |
| Recommended pairing | Matches with fabric modular sofas, round side tables and light neutral area rugs |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
