Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (closed nested position) | 900 x 900 x 380 mm | |
|---|---|---|
| Lower tier diameter | 900 mm | |
| Upper rotating tier diameter | 700 mm | |
| Lower tier plinth height | 250 mm | |
| Upper rotating tier height (top of surface) | 380 mm | |
| Tabletop thickness (both tiers) | 25 mm | |
| Maximum extended offset (upper tier rotated) | 400 mm | |
| Plinth base wall thickness | 3 mm | |
| Floor clearance under plinth | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static load per tier | 59 kg | |
|---|---|---|
| Product net weight | 64 kg | |
| Rotation mechanism cycle rating | 15000 cycles | |
| Surface scratch resistance (pencil hardness) | 3H | |
| Water and stain resistance rating | Level 4 | |
| Recommended maximum decorative item weight on upper tier | 25 kg | |
| Warranty period for residential use | 90 days | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Lower tier plinth and top substrate | 1.2mm thick cold-rolled steel | |
|---|---|---|
| Upper tier plinth and top substrate | 1.2mm thick cold-rolled steel | |
| Tabletop surface coating | Electroplated metallic finish with clear anti-scratch topcoat | |
| Rotation swivel bearing | Zinc-plated steel heavy-duty lazy susan bearing | |
| Plinth base bottom padding | 2mm thick non-slip EVA felt pads | |
| Edge banding | Fully welded and polished rounded steel edge | |
| Internal plinth reinforcement | 1.5mm thick steel cross bracing | |
| Finish type (lower tier) | Brushed bronze PVD plating | |
| Finish type (upper tier) | Brushed silver chrome plating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| 360° upper tier rotation | Upper tier rotates freely around central bearing to create extended surface area | |
|---|---|---|
| Nested space-saving design | Upper tier sits concentrically over lower tier when not in use | |
| Offset extended serving position | Upper tier rotates to partially extend beyond lower tier perimeter | |
| Floor protection function | Non-slip felt pads on plinth base prevent scuffing on carpet and hard floors | |
| Easy maintenance surface | Sealed metallic finish wipes clean with dry or damp microfiber cloth | |
| Tool-free setup | Pre-assembled nested tiers require no on-site assembly | |
| Anti-wobble stability | Wide low plinth base creates low center of gravity to prevent tipping | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room placement | Position directly in front of 3-seat or L-shaped sofas for beverage and decor display | |
|---|---|---|
| Luxury residential use | Suitable for modern, contemporary, or minimalist luxury interior design schemes | |
| Lounge and reception areas | Appropriate for upscale office reception lounges and hotel lobby seating zones | |
| Small apartment space optimization | Rotating nested design expands usable surface without requiring large permanent footprint | |
| Decor display primary use | Supports stacked books, sculptural objects, and table lamps on dual offset surfaces | |
| Recommended floor surfaces | Safe for low-pile carpet, hardwood, luxury vinyl tile, and polished concrete floors |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Furniture – Strength, durability and safety for domestic tables applicable to performance verification | |
|---|---|---|
| EN 12521:2015 | Furniture – Mechanical safety requirements for domestic tables applicable to stability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture applicable to quality inspection of metal-framed living room tables | |
|---|---|---|
| GB/T 4893.8-2013 | Surface wear resistance test method applicable to verification of metallic top durability | |
| GB/T 4893.1-2021 | Surface liquid resistance test method applicable to anti-stain performance checks | |
| GB/T 10357.1-2013 | Table static load test method applicable to load capacity verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture applicable to quality inspection of metal-framed living room tables; 2. GB/T 4893.8-2013: Surface wear resistance test method applicable to verification of metallic top durability; 3. GB/T 4893.1-2021: Surface liquid resistance test method applicable to anti-stain performance checks; 4. GB/T 10357.1-2013: Table static load test method applicable to load capacity verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
