Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 800 × 700 × 460 mm | |
|---|---|---|
| Overall large table dimensions | 800 x 700 x 460 mm | |
| Overall small table dimensions | 800 x 600 x 400 mm | |
| Tabletop thickness | 15 mm | |
| Leg cross-section at top | 30 x 30 mm | |
| Leg cross-section at floor contact | 15 x 15 mm | |
| Nesting clearance under large table | 390 mm | |
| Floor gap under large table apron | 430 mm | |
| Corner leg offset from table edge | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static load per tabletop | 50 kg | |
|---|---|---|
| Net weight of large table | 22 kg | |
| Surface heat resistance | 120 °C | |
| Surface abrasion resistance | 2000 cycles | |
| Floor protector load rating per leg | 20 kg | |
| Recommended maximum display item weight | 15 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Large tabletop | Black veined sintered stone-look engineered surface, matte smooth finish | |
|---|---|---|
| Small tabletop | White marble-effect sintered stone-look engineered surface, matte smooth finish | |
| Legs and frame | 1.2mm thick powder-coated black carbon steel, tapered square profile | |
| Table edge treatment | Eased polished square edge, no raised lip | |
| Floor contact pads | 3mm thick non-slip rubber pads, pre-attached to leg bottoms | |
| Frame connection hardware | M8 zinc-plated steel bolts and lock nuts | |
| Underside support battens | 15mm thick powder-coated steel crossbars under each tabletop | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Nesting storage function | Small table slides fully under large table to reduce footprint when not in use | |
|---|---|---|
| Dual-surface use function | Both tables provide independent flat display surfaces for drinks, reading materials and decor | |
| Surface cleaning function | Smooth non-porous surfaces wipe clean with a soft damp cloth, no harsh detergents required | |
| Floor protection function | Pre-attached rubber leg pads prevent scuffs and scratches on hard floors and rugs | |
| Flexible arrangement function | Tables can be separated for side table use or positioned together as a larger combined surface | |
| Static level stability | Fixed four-leg design provides stable non-rocking placement on flat even floors | |
| Interlocking overlap depth when nested | 600 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential living room use | Placed in front of sofas or sectionals as a central coffee table for daily leisure and display | |
|---|---|---|
| Small apartment and studio use | Nesting design saves floor space when extra surface area is not required | |
| Modern and light luxury interiors | Black and white two-tone stone finish coordinates with minimalist, contemporary and neutral decor schemes | |
| Temporary event display use | Lightweight separate tables can be moved to hold refreshments or decor for small home gatherings | |
| Home office lounge use | Can be placed in reception or break areas to hold reading materials and beverages for guests |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, recommended for structural performance verification | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface resistance to cold liquids, recommended for tabletop stain resistance checks |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to surface finish and structural stability inspection | |
|---|---|---|
| GB/T 4893.4-2013 | Surface wear resistance test method for furniture finishes, recommended for tabletop durability validation | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to finish emission testing for interior use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to surface finish and structural stability inspection; 2. GB/T 4893.4-2013: Surface wear resistance test method for furniture finishes, recommended for tabletop durability validation; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to finish emission testing for interior use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
