Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (nested) | 800 x 800 x 550 mm | |
|---|---|---|
| Large coffee table top diameter | 800 mm | |
| Large coffee table overall height | 450 mm | |
| Large table sintered stone top thickness | 12 mm | |
| Large table base outer diameter | 760 mm | |
| Small side table top diameter | 550 mm | |
| Small side table overall height | 550 mm | |
| Small table C-frame leg clearance under top | 480 mm | |
| Small table upholstered cylinder diameter | 450 mm | |
| Large table drawer internal usable depth | 300 mm | |
| Small table top black trim width | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Large table distributed static load capacity | 50 kg | |
|---|---|---|
| Sintered stone top heat resistance | 1200 °C | |
| Sintered stone top Mohs hardness | 7 | |
| Set total net weight | 60 kg | |
| Large table drawer static load per drawer | 10 kg | |
| Finish abrasion resistance (lacquer base) | Grade 2 | |
| Recommended number of users | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large table top | 12mm polished white sintered stone, scratch and stain resistant | |
|---|---|---|
| Large table base structure | Matte grey lacquered MDF cylindrical body with internal metal support frame | |
| Large table drawer components | Soft-close drawer slides, lacquered MDF drawer fronts matching base finish | |
| Small table top | 10mm white sintered stone with 20mm black metal edge trim | |
| Small table support frame | 1.5mm thick matte black carbon steel C-frame with round base plate | |
| Small table lower cylinder | High-density fiberboard core wrapped in black-and-white houndstooth woven fabric | |
| Table foot pads | Non-slip 5mm thick EVA rubber pads fixed to base bottoms | |
| Hardware connectors | Zinc-plated steel cam lock and screw fasteners for assembly | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Nesting space-saving design | Small C-frame table slides partially under the large table base to reduce footprint when not in use | |
|---|---|---|
| Large table integrated storage | Two pull-out drawers built into the cylindrical base for living room accessory storage | |
| Surface heat resistance | Sintered stone tops support direct placement of hot drinkware and serving dishes up to 1200°C | |
| Scratch and stain resistance | Non-porous sintered stone tops resist liquid stains and abrasion from daily use items | |
| Floor protection | EVA foot pads prevent scratching of hard flooring and snagging of area rugs | |
| Coordinated multi-surface use | Two differing height tables provide separate surfaces for drinks, decor, reading materials and snacks | |
| No-tool assembly | Knock-down assembly requires only included hex key for base and top connection | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room seating areas | Placed in front of 4seat sofas for serving drinks, snacks and media accessories | |
|---|---|---|
| Small apartment and compact homes | Nesting design reduces unused floor space when extra surface area is not needed | |
| Modern light luxury interior schemes | Two-tone grey/white scheme with houndstooth detail matches minimalist and contemporary decor | |
| Open-plan lounge and reception spaces | Dual surfaces support casual guest hosting and daily household use | |
| Rug-protected soft flooring areas | Smooth base and rubber foot pads are safe for low-pile area rugs and hard flooring | |
| Studio apartment multi-use spaces | Nested configuration frees floor space for exercise or temporary work activities |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable for load testing | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface finishes of furniture, applicable to lacquer durability | |
| EN 71-3:2019 | Safety of toys – Migration of certain elements, applicable for fabric finish chemical safety |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to lacquered MDF base components | |
|---|---|---|
| GB/T 4085-2015 | Sintered stone for furniture, applicable to table top material performance verification | |
| GB 18584-2001 | Indoor decorating and refurbishing materials – limit of harmful substances for wooden furniture | |
| GB/T 191-2008 | Packaging storage and transportation pictorial markings for furniture delivery packaging |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to lacquered MDF base components; 2. GB/T 4085-2015: Sintered stone for furniture, applicable to table top material performance verification; 3. GB 18584-2001: Indoor decorating and refurbishing materials – limit of harmful substances for wooden furniture; 4. GB/T 191-2008: Packaging storage and transportation pictorial markings for furniture delivery packaging; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
