Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 800 × 450 mm | |
|---|---|---|
| Overall assembled dimensions | 1400 x 800 x 450 mm | |
| Tabletop thickness | 23 mm | |
| Base floor plate dimensions | 700 x 350 x 12 mm | |
| Vertical support metal wall thickness | 2 mm | |
| Floor clearance under table base frame | 100 mm | |
| Corner radius of tabletop | 30 mm | |
| Support beam width (grey accent panel) | 80 mm | |
| Tabletop overhang beyond base edges | 200 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load capacity | 50 kg | |
|---|---|---|
| Product net weight | 45 kg | |
| Powder coat finish abrasion resistance | 2000 cycles | |
| Tabletop surface stain resistance rating | Grade 4 | |
| Base weld joint static load safety factor | 3:1 | |
| Floor contact point load per support plate | 23 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop slab | White veined sintered stone, polished sealed surface | |
|---|---|---|
| Primary base frame | Matte black powder-coated carbon steel, welded construction | |
| Accent support panel | Brushed grey powder-coated carbon steel, welded to black frame | |
| Bottom floor plate | Matte black carbon steel, welded to vertical supports | |
| Tabletop underside backing | 15 mm thick MDF reinforcement panel | |
| Floor contact pads | Non-slip EVA rubber pads, 3 mm thick, attached to base plate corners | |
| Connecting hardware | M8 zinc-plated steel bolts and lock washers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Fixed 450 mm height, no extendable or lift mechanisms | |
|---|---|---|
| Storage function | No built-in drawers, shelves or hidden compartments | |
| Mobility | Fixed position, no integrated casters or rolling components | |
| Assembly requirement | Knockdown assembly required, attaches top to base with included hardware | |
| Surface use case | Smooth non-porous top supports drinks, books and decorative items | |
| Floor protection | Integrated rubber pads prevent scratching on hard floors and rugs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Suitable room size | 30sqm living areas, open-plan lounge spaces | |
|---|---|---|
| Style matching | Complements modern minimalist, Italian minimalist, contemporary luxury interiors | |
| Recommended pairing | Coordinates with matching side tables of identical base and top design | |
| User profile | Ideal for homeowners, rental properties and modern apartment staging | |
| Surface use suitability | Supports placement of coffee service, reading materials, and small decorative objects |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 15372:2008 | Safety, strength and durability requirements for domestic non-upholstered tables | |
|---|---|---|
| EN 12521:2015 | Functional dimensions and safety requirements for residential seating area tables |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to backing panel construction | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard specifications for structural use in furniture backing panels | |
| GB 18584-2001 | Limits of harmful substances released from wooden furniture materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to backing panel construction; 2. GB/T 4897.3-2015: Particleboard specifications for structural use in furniture backing panels; 3. GB 18584-2001: Limits of harmful substances released from wooden furniture materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
