Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 750 × 450 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Leg width (single U-leg) | 180 mm | |
| Leg height (floor to tabletop underside) | 438 mm | |
| Leg wall thickness | 8 mm | |
| Corner radius (tabletop rounded edge) | 30 mm | |
| Floor clearance under table center | 380 mm | |
| Tabletop overhang beyond leg outer edge | 50 mm | |
| Distance between two supporting legs | 900 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Assembled net weight | 45 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 50 kg | |
| Sintered stone surface heat resistance | 180 °C | |
| Powder coat finish abrasion resistance | 2000 cycles | |
| Leg floor load per contact point | 14 kg | |
| Recommended maximum single-point placed load | 20 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 12mm polished sintered stone with linear grey veining, soft rounded corners | |
|---|---|---|
| Tabletop edge finish | Polished straight cut edge matching surface finish | |
| Supporting legs | 8mm thick welded steel plate with dark bronze matte powder coat | |
| Leg floor contact pads | Non-marking anti-slip rubber pads at each leg base | |
| Tabletop-to-leg connection hardware | M8 zinc-plated steel bolts with pre-installed threaded inserts | |
| Metal surface treatment | Matte anti-fingerprint powder coating, corrosion resistant for indoor use | |
| Sintered stone surface property | Non-porous, stain-resistant polished finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Structural design | Fixed rigid structure with no moving parts, lift mechanism or storage compartments | |
|---|---|---|
| Surface function | Flat polished top suitable for placing drinks, decor, books and light serving items | |
| Leveling adjustment | Optional removable adjustable foot pads under each leg to compensate for uneven floors | |
| Cleaning function | Non-porous stone surface allows wipe-clean maintenance with standard household cleaners | |
| Assembly configuration | Flat-pack assembly requiring leg attachment to tabletop underside with included hardware | |
| Floor protection | Rubber contact pads prevent metal leg scuffing on hard flooring and low-pile carpet | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary application space | Residential living rooms, positioned directly in front of standard sofas | |
|---|---|---|
| Secondary application space | Modern apartment open-plan lounge areas, hotel executive lounge seating zones | |
| Recommended matching furniture | Low-profile fabric or leather sofas with 450 mm seat height | |
| Suitable user groups | Design-focused residential buyers, small apartment dwellers, boutique commercial lounge operators | |
| Usage notes | Intended for indoor dry environment use only, not suitable for outdoor exposure | |
| Recommended placement | Centered 400 mm from front edge of sofa for easy access to placed items |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture for domestic use, tables, strength and safety requirements for structural verification | |
|---|---|---|
| EN 15187:2006 | Furniture, test for assessment of surface resistance to dry heat for tabletop performance |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability verification | |
|---|---|---|
| GB/T 4893.4-2013 | Surface abrasion resistance test for furniture surfaces, applicable for finish durability acceptance | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for indoor air quality verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability verification; 2. GB/T 4893.4-2013: Surface abrasion resistance test for furniture surfaces, applicable for finish durability acceptance; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for indoor air quality verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
