Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1100 x 560 x 480 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Tabletop corner radius | 30 mm | |
| Leg tubular section size | 40 x 20 mm | |
| Metal base wall thickness | 1.5 mm | |
| Floor clearance under tabletop | 455 mm | |
| Base footprint width | 520 mm | |
| Base footprint length | 1040 mm | |
| Under-table knee clearance height | 420 mm | |
| Non-slip foot pad diameter | 25 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static distributed load capacity | 91 kg | |
|---|---|---|
| Net product weight | 8.5 kg | |
| Top surface impact resistance | 1.2 J | |
| Metal frame static load per leg | 30 kg | |
| Finish abrasion resistance (tabletop) | 2000 cycles | |
| Powder coat finish scratch resistance (base) | 3H pencil hardness | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | High-density MDF engineered wood board | |
|---|---|---|
| Tabletop surface | White grey-veined faux marble thermofused laminate | |
| Support frame and legs | Cold-rolled steel tubing | |
| Metal finish | Matte black electrostatic powder coating | |
| Foot pads | TPU non-slip non-marking protective pads | |
| Assembly hardware | Zinc-plated steel bolts and barrel nuts | |
| Cross support bar | Same rectangular steel tubing as leg sections | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Floor protection | Non-slip TPU pads on each leg to prevent scuffing and sliding on hard floors or rugs | |
|---|---|---|
| Impact safety | Rounded tabletop corners to reduce injury risk from bumps in high-traffic living areas | |
| Assembly requirement | Flat-pack assembly with included hex key and illustrated instructions | |
| Frame stability | Central cross-braced geometric leg structure eliminates wobble on level surfaces | |
| Surface maintenance | Water-resistant non-porous top wipes clean with damp cloth, no special sealant required | |
| Level adjustment | Fixed foot pads accommodate minor floor unevenness up to 2 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential living rooms positioned in front of sectional or standard sofas | |
|---|---|---|
| Suitable room size | Small to medium living areas 25sqm | |
| Design style compatibility | Modern, minimalist, industrial, and contemporary interior schemes | |
| Recommended complementary furniture | Low-pile area rugs, fabric or leather modular sofas, neutral-toned accent seating | |
| Commercial secondary use | Office lounge breakout areas, hotel reception waiting zones |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable to load and stability testing | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface finishes, applicable to laminate top abrasion and stain resistance | |
| EN 1022:2005 | Furniture – Seating – Determination of stability, referenced for adjacent seating area use safety |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop core and finish performance | |
|---|---|---|
| GB/T 24821-2009 | Performance requirements for metal furniture frames, applicable to steel base structural integrity | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to MDF core formaldehyde emissions |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop core and finish performance; 2. GB/T 24821-2009: Performance requirements for metal furniture frames, applicable to steel base structural integrity; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to MDF core formaldehyde emissions; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
