Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 810 × 810 × 460 mm | |
|---|---|---|
| Overall set footprint (fully nested) | 810 x 810 x 460 mm | |
| Large table diameter | 810 mm | |
| Large table top surface height | 460 mm | |
| Large tabletop thickness | 12 mm | |
| Large table metal rim height | 15 mm | |
| Large table leg tube diameter | 20 mm | |
| Large table cross-brace span | 700 mm | |
| Small table diameter | 610 mm | |
| Small table top surface height | 500 mm | |
| Small tabletop thickness | 12 mm | |
| Small table leg base footprint | 500 x 300 mm | |
| Nesting insertion depth | 380 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set net weight | 26 kg | |
|---|---|---|
| Large table distributed static load capacity | 100 kg | |
| Frame static stability load | 150 kg | |
| Tabletop surface abrasion resistance | ≥6000 cycles | |
| Tabletop heat resistance threshold | 180 °C | |
| Color variant count | 4 | |
| Residential use warranty | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Large tabletop | 12mm white marble-vein sintered stone | |
|---|---|---|
| Small tabletop | 12mm black marble-vein sintered stone | |
| Table edge rims | 20mm wide matte black powder-coated steel | |
| Large table frame | 20mm diameter tubular black powder-coated steel | |
| Small table frame | 20mm diameter tubular black powder-coated steel | |
| Frame finish | 80μm thick matte black powder coating | |
| Frame connectors | M6 hex bolts with lock washers | |
| Foot pads | 8mm diameter non-slip plastic floor glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Nesting storage function | Small table slides 380mm under large table to reduce footprint | |
|---|---|---|
| Raised edge retention | 15mm metal rim prevents small items, cups, books from sliding off | |
| Flexible configuration | Set separates to use large table as main coffee table, small as side end table | |
| Surface cleaning | Non-porous sintered stone top wipes clean with damp cloth, no sealing required | |
| Floor protection | Non-slip plastic glides on all leg ends prevent scuffs on hard floors and rugs | |
| Quick assembly | Frame attaches to tabletop with included hex key, no specialized tools needed | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Primary use | Living room placement in front of upholstered sofas for holding drinks, books, and decor | |
|---|---|---|
| Suitable space size | Small to medium apartments, studio units, and compact lounge areas | |
| Flexible side use | Small table can be pulled out for use beside armchairs or as extra serving surface during gatherings | |
| Style matching | Complements modern minimalist, light luxury, industrial, and contemporary interior design schemes | |
| Recommended pairing | Pair with low-pile area rugs, 3-seat upholstered sofas, and neutral-toned seating furniture | |
| Commercial use | Suitable for hotel lounge areas, office reception zones, and apartment common spaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture strength and stability | EN 12521:2015 | |
|---|---|---|
| Surface emission safety | EN 13986:2004 | |
| Metal coating durability | EN 12720:2009 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop material safety | GB 6566 | |
|---|---|---|
| Metal furniture structural safety | GB/T 3324 | |
| Furniture surface coating safety | GB 18584 |
This product must meet the following technical requirements: 1. Tabletop material safety: GB 6566; 2. Metal furniture structural safety: GB/T 3324; 3. Furniture surface coating safety: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
