Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (nested configuration) | 900 x 900 x 457 mm | |
|---|---|---|
| Large coffee table diameter | 813 mm | |
| Large coffee table tabletop height | 457 mm | |
| Large coffee table tabletop thickness | 15 mm | |
| Small side table diameter | 610 mm | |
| Small side table tabletop height | 550 mm | |
| Small side table tabletop thickness | 15 mm | |
| Large table metal leg tube section | 30 x 30 mm | |
| Small table metal leg tube section | 25 x 25 mm | |
| Underside floor clearance | 20 mm | |
| Small table nest clearance under large table | 300 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set net weight | 26 kg | |
|---|---|---|
| Large table distributed static load capacity | 50 kg | |
| Frame finish rust resistance rating | 500 hours salt spray | |
| Tabletop surface stain resistance | Grade 5 | |
| Tabletop surface abrasion resistance | 2000 cycles | |
| Foot pad static floor protection rating | 100 kg per pad | |
| Recommended maximum weight per tabletop point load | 10 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large table tabletop | Engineered artificial marble with white base and grey veining, polished smooth surface | |
|---|---|---|
| Small table tabletop | Matching white veined engineered artificial marble, rounded polished edge | |
| Large table support frame | Matte black powder-coated carbon steel, X-brace cross support with perimeter base | |
| Small table support frame | Matte black powder-coated carbon steel, open rectangular sled-style leg base | |
| Frame connection hardware | Zinc-plated steel bolts and lock washers, M6 size for rigid assembly | |
| Floor contact foot pads | Non-slip injection-molded PVC pads, adjustable height for leveling | |
| Tabletop underside support | 1.2mm thick steel support rails bonded and screwed to tabletop | |
| Frame surface coating | Epoxy-polyester powder coat, 60 micron thickness, matte black finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Nesting space-saving function | Small table slides partially under the large table to reduce total footprint by 40% when not in use | |
|---|---|---|
| Leveling adjustment | Rotating PVC foot pads adjust up to 5mm to compensate for uneven hard floors | |
| Surface cleaning function | Non-porous tabletop wipes clean with a damp cloth, resistant to common household beverage stains | |
| Dual-use configuration | Tables separate to provide two independent surfaces for drinks, decor, or reading materials in seating areas | |
| Floor protection function | Soft PVC foot pads prevent scuffing and scratching on polished tile, wood, or vinyl flooring | |
| Assembly connection | Knock-down frame attaches to tabletops with included hex key and hardware, no specialized tools required | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room placement | Positioned in front of sectional sofas to hold drinks, books, and decorative displays | |
|---|---|---|
| Small apartment and studio use | Nesting function reduces footprint when extra surface space is not required | |
| Lounge and reception area use | Suitable for office break rooms or boutique waiting areas to serve guest refreshments | |
| Flexible side surface use | Separated small table functions as an end table beside accent chairs or sofa ends | |
| Recommended floor surfaces | Safe for polished tile, engineered wood, laminate, and vinyl flooring without additional protection | |
| Recommended decor styles | Complements contemporary, minimalist, Nordic, and light luxury interior design schemes |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic tables, applicable to overall structural validation | |
|---|---|---|
| EN 15187:2006 | Furniture assessment of surface resistance to dry heat, applicable to tabletop finish performance checks |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate performance verification | |
|---|---|---|
| GB/T 4893.8-2013 | Furniture surface test for abrasion resistance, applicable to tabletop finish durability checks | |
| GB/T 10357.1-2013 | Furniture mechanical test for table static load, applicable to frame and tabletop load validation | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable to substrate emission checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate performance verification; 2. GB/T 4893.8-2013: Furniture surface test for abrasion resistance, applicable to tabletop finish durability checks; 3. GB/T 10357.1-2013: Furniture mechanical test for table static load, applicable to frame and tabletop load validation; 4. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable to substrate emission checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
