Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 700 x 420 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight range | 28 kg | |
|---|---|---|
| Tabletop static load capacity | 50 kg | |
| Recommended occupancy support | 4 people | |
| Surface scratch resistance rating | 3000 cycles | |
| Recommended warranty period | 2 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18mm MDF core with laminated stone-effect veneer | |
|---|---|---|
| Tabletop surface finish | Matte semi-gloss patterned dark grey stone print | |
| Frame and base material | Powder-coated carbon steel tubing | |
| Frame surface coating | Matte black epoxy powder coat, 80μm thickness | |
| Frame joint construction | Welded joints with ground smooth finish | |
| Foot pads | 8mm non-slip polyethylene glides at all base contact points | |
| Tabletop edge retention | Steel frame lip holding tabletop inset to prevent lateral shift | |
| Cross-bracing structure | 25mm square steel tube cross bracing connecting four base corners | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Floor protection function | Inset polymer glides prevent floor scratching on hard flooring and carpet | |
|---|---|---|
| Surface usability | Seamless framed tabletop supports drink service, decor display, and light daily use | |
| Structural stability | Four-point angled leg design with cross bracing eliminates wobble on level surfaces | |
| Cleaning suitability | Smooth non-porous tabletop surface supports wipe-clean maintenance with standard household cleaners | |
| Assembly requirement | Knock-down assembly with included hex key hardware connecting frame sections to leg assembly | |
| Leveling adjustment | Fixed glides with no adjustable thread, requires level floor for stable placement | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 1250 x 750 x 120 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living rooms | Placed in front of sofas for beverage service and display, suitable for apartment and house settings | |
|---|---|---|
| Office lounge areas | Used in reception breakout zones for guest refreshment and casual meeting placement | |
| Modern minimalist interiors | Matches monochrome and industrial decor schemes with matte black frame and stone-effect finish | |
| Rental and staging properties | Durable easy-clean construction suitable for short-term rental furnishing and home staging projects | |
| Small-space layouts | Open base design creates visual lightness suitable for compact living areas without visual clutter |
EU Market Access Requirements* EN Standards
| Surface durability standard | EN 15187:2006 | |
|---|---|---|
| Structural strength standard | EN 12521:2015 |
Standards applicable to China-market projects
| Surface performance standard | GB/T 4897.3 | |
|---|---|---|
| Metal coating standard | GB/T 19001 | |
| Furniture stability standard | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Surface performance standard: GB/T 4897.3; 2. Metal coating standard: GB/T 19001; 3. Furniture stability standard: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
