Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 800 x 800 x 460 mm | |
|---|---|---|
| tabletop thickness | 12 mm | |
| lower shelf thickness | 8 mm | |
| metal frame tube section | 40 x 20 mm | |
| metal frame wall thickness | 1.5 mm | |
| lower shelf clearance from floor | 50 mm | |
| vertical gap between top and lower shelf | 280 mm | |
| frame foot pad diameter | 25 mm | |
| lower shelf outer dimension | 760 x 760 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| tabletop static distributed load | 50 kg | |
|---|---|---|
| lower shelf static distributed load | 30 kg | |
| net product weight | 30 kg | |
| recommended maximum seated user edge load | 80 kg | |
| powder coating film thickness | 80 um | |
| tempered glass impact resistance | 1 kg steel ball drop from 1m height | |
| frame joint cyclic load durability | 10000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop surface | White marble-vein finish on tempered glass/engineered stone substrate | |
|---|---|---|
| support frame | Black powder-coated carbon steel rectangular tube | |
| lower storage shelf | 8mm thick CCC-certified black glossy tempered glass | |
| frame foot pads | Non-slip TPE rubber | |
| fasteners | Zinc-plated steel hex bolts and lock nuts | |
| tabletop edge trim | Matte black PVC/ABS edge banding | |
| lower shelf frame retainer | Black powder-coated steel channel | |
| frame surface treatment | Electrostatic polyester powder coating | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| storage configuration | Fixed double-tier design with open lower shelf | |
|---|---|---|
| frame stability | X-cross bracing integrated between top and base | |
| floor protection | Rubber foot pads fitted at all frame base contact points | |
| assembly design | Flat-pack bolted assembly with pre-drilled frame holes | |
| shelf retention | Lower glass secured by recessed metal channel frame | |
| surface maintenance | Non-porous polished top and glass shelf surfaces | |
| structural rigidity | Interlocking X-frame members connect upper apron to lower base | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| shipping carton dimensions | 900 x 900 x 150 mm | |
|---|---|---|
| shipping gross weight | 35 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| living room placement | Positioned in front of sofas for holding drinks, decor and reading materials | |
|---|---|---|
| small apartment use | Compact 800mm square footprint fits limited floor space in studio or small living areas | |
| contemporary interior settings | Black and white marble-look finish matches modern, minimalist and luxury interior schemes | |
| reception area use | Suitable for office reception lounges to hold magazines and visitor refreshments | |
| residential lounge configuration | Pairs with 3seater sofas or modular sectional seating | |
| hard flooring compatibility | Rubber foot pads safe for hardwood, tile, vinyl and polished concrete floors |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic coffee tables | |
|---|---|---|
| EN 12150-1:2015 | Thermally toughened soda lime silicate safety glass for furniture use | |
| EN 10346:2015 | Continuously hot-dip coated steel flat products for furniture frames |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for top substrate verification | |
|---|---|---|
| GB 15763.2-2005 | Safety requirements for tempered glass used in furniture, applicable for both glass shelves | |
| GB/T 1732-1993 | Impact resistance test standard for metal furniture paint films | |
| GB/T 4893.8-2013 | Surface wear resistance test for furniture surfaces, applicable for top finish |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for top substrate verification; 2. GB 15763.2-2005: Safety requirements for tempered glass used in furniture, applicable for both glass shelves; 3. GB/T 1732-1993: Impact resistance test standard for metal furniture paint films; 4. GB/T 4893.8-2013: Surface wear resistance test for furniture surfaces, applicable for top finish; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
