Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (large table deployed, small table nested) | 900 x 900 x 470 mm | |
|---|---|---|
| Large table diameter | 900 mm | |
| Large table total height (floor to tabletop) | 470 mm | |
| Small table diameter | 600 mm | |
| Small table total height (floor to tabletop) | 430 mm | |
| Tabletop thickness | 15 mm | |
| Large pedestal base diameter | 450 mm | |
| Small pedestal base diameter | 300 mm | |
| Pedestal base wall thickness | 1.5 mm | |
| Floor clearance under large table overhang | 300 mm | |
| Tabletop edge bevel width | 5 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set net weight | 50 kg | |
|---|---|---|
| Large table distributed static load capacity | 50 kg | |
| Surface scratch resistance rating | Class 2 (≥2000 abrasion cycles) | |
| Surface heat resistance (temporary contact) | 120 °C | |
| Stability tilt load (200mm from table edge) | 15 kg | |
| Standard product warranty | 3 years | |
| Available finish variants | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Large table tabletop | 15mm polished marble-veined sintered stone panel with high-gloss clear sealant | |
|---|---|---|
| Small table tabletop | 15mm polished marble-veined sintered stone panel, matching large table pattern and finish | |
| Large table pedestal base | 1.5mm thick carbon steel cylinder with brushed brass PVD titanium coating | |
| Small table pedestal base | 1.5mm thick carbon steel cylinder with brushed brass PVD titanium coating, matching large base finish | |
| Base floor contact pads | 5mm thick non-slip EVA rubber pads bonded to base bottom | |
| Tabletop-to-base connection | M8 zinc-plated steel mounting bolts with threaded metal inserts in base top plate | |
| Tabletop underside reinforcement | 12mm thick MDF balancing panel bonded to stone top bottom | |
| Surface finish coating | Anti-fingerprint nano-ceramic clear top coat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Nesting storage function | Small table slides fully under large table overhang to reduce footprint to 0.81 m² when not in use | |
|---|---|---|
| Knock-down assembly | Tables assemble with 4 bolts per table using a standard Phillips screwdriver, no special tools required | |
| Surface use suitability | Glossy sealed top supports drinkware, decor, books and snacks with stain and water resistance | |
| Independent use capability | Each table functions as a standalone coffee or side table when separated for flexible layout | |
| Floor protection function | EVA base pads prevent scratching hard flooring and eliminate sliding noise during repositioning | |
| Leveling adjustment | Hidden adjustable feet on base bottom allow 5mm height adjustment for uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Modern living room main seating area | Placed in front of 3seater sofas for shared drink and decor placement | |
|---|---|---|
| Small apartment flexible layout | Nested configuration saves floor space when additional surface area is not required | |
| Luxury residential lounge space | Brass finish and marble veining complement light luxury and contemporary interior schemes | |
| Reception waiting area use | Suitable for placing reading materials and refreshments for guests in office reception zones | |
| Open-plan lounge divider setup | Separated tables create functional zoning between living and dining zones without blocking sightlines |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining and living tables | |
|---|---|---|
| EN 13722:2004 | Test methods for furniture table stability and structural integrity |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF reinforcement components | |
|---|---|---|
| GB/T 4893.4-2013 | Surface wear resistance test method for furniture finishes, applicable to tabletop coating | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to adhesive and finish materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF reinforcement components; 2. GB/T 4893.4-2013: Surface wear resistance test method for furniture finishes, applicable to tabletop coating; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to adhesive and finish materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
