Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 450 mm | |
|---|---|---|
| Upper tabletop thickness | 10 mm | |
| Lower storage shelf thickness | 8 mm | |
| Leg cross-section size | 50 x 50 mm | |
| Leg wall thickness | 1.2 mm | |
| Lower shelf vertical clearance from floor | 120 mm | |
| Vertical clearance between upper top and lower shelf | 220 mm | |
| Glass overhang past leg frame perimeter | 30 mm | |
| Mounting pad diameter at glass-leg connection points | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total tabletop static distributed load capacity | 105 kg | |
|---|---|---|
| Product net weight | 23 kg | |
| Tempered glass impact resistance rating | ANSI Z97.1 safety glass standard | |
| Chrome finish corrosion resistance | 48 hours neutral salt spray resistance | |
| Recommended maximum seated user edge load | 40 kg | |
| Expected service life under residential use | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upper tabletop | 10mm black back-painted tempered safety glass | |
|---|---|---|
| Lower open storage shelf | 8mm black back-painted tempered safety glass | |
| Vertical support legs | Polished chrome-plated square steel tube, 1.2mm wall thickness | |
| Horizontal lower support rails | Polished chrome-plated steel tube, 1.2mm wall thickness | |
| Glass mounting hardware | Zinc alloy chrome-plated clamping pads with rubber gaskets | |
| Adjustable foot pads | Nylon base with threaded steel insert, 10mm adjustment range | |
| Glass surface coating | Heat-resistant scratch-resistant nano-coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Open lower shelf storage | Fixed flat shelf for books, magazines and small living room items | |
|---|---|---|
| Flat-pack KD assembly | Bolts connect glass panels to metal frame via pre-installed clamping hardware | |
| Adjustable floor leveling | Threaded foot pads adjust up to 10mm to compensate for uneven floors | |
| Heat-resistant top surface | Tempered glass supports hot beverage containers up to 120°C without damage | |
| Non-marring surface contact | Rubber gaskets between metal clamps and glass prevent scratches and stress cracks | |
| Easy cleaning maintenance | Smooth non-porous glass and polished chrome surfaces wipe clean with damp soft cloth | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential living room placement | Positioned in front of sofas for holding beverages, snacks and decorative items | |
|---|---|---|
| Office reception area use | Placed between guest seating for waiting areas in modern office fit-outs | |
| Small apartment lounge application | Open lower shelf adds storage without visual bulk for compact living spaces | |
| Apartment rental furnishing | Durable glass and metal construction for long-term rental property use | |
| Modern minimalist interior scheme | Coordinates with monochrome, contemporary and industrial style decors | |
| Light commercial lounge use | Suitable for hotel lobbies and breakout areas with low to medium traffic |
EU Market Access Requirements* EN Standards
| Glass furniture safety | EN 12150:2015 | |
|---|---|---|
| Furniture mechanical stability | EN 1730:2012 | |
| Furniture surface resistance | EN 12720:2013 | |
| Furniture emission limits | EN 16516:2017 |
Standards applicable to China-market projects
| Tempered glass safety | GB 15763.2 | |
|---|---|---|
| Furniture structural stability | GB/T 10357.1 | |
| Furniture surface durability | GB/T 4893.4 | |
| Metal furniture coating adhesion | GB/T 1979 |
This product must meet the following technical requirements: 1. Tempered glass safety: GB 15763.2; 2. Furniture structural stability: GB/T 10357.1; 3. Furniture surface durability: GB/T 4893.4; 4. Metal furniture coating adhesion: GB/T 1979; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
