Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 450 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Metal frame tube profile | 30 x 30 mm | |
| Vertical leg height | 425 mm | |
| Longitudinal frame span | 1140 mm | |
| Transverse frame span | 540 mm | |
| Bottom frame clearance above floor | 50 mm | |
| Tabletop edge overhang | 30 mm | |
| Metal tube wall thickness | 1.2 mm | |
| Internal center support crossmember position | 600 mm from each table end | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net product weight | 18 kg | |
|---|---|---|
| Tabletop static load capacity | 50 kg | |
| Recommended maximum placemat size | 400 x 300 mm | |
| Recommended user capacity | 4 | |
| Frame static load rating | 100 kg | |
| Surface abrasion resistance | 300 cycles | |
| Board substrate moisture content | 12% | |
| Powder coating adhesion rating | Grade 1 | |
| Frame wobble tolerance on level floor | 1 mm | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | 18 mm thick particleboard core | |
|---|---|---|
| Tabletop surface finish | Melamine laminate with walnut wood grain print | |
| Frame material | Cold-rolled square steel tube | |
| Frame finish | Matte black powder coating | |
| Frame connection hardware | Black oxide finished steel screws and welded joints | |
| Foot contact pads | 30 mm diameter injection-molded plastic glides | |
| Tabletop edge banding | 1 mm thick PVC edge banding | |
| Frame weld joints | Full penetration MIG welds at all tube intersections | |
| Hardware fastener count | 12 pieces | |
| Substrate formaldehyde emission class | E1 grade | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Fixed stable support | Four-point floor contact with open perimeter frame eliminates wobble on level hard floors | |
|---|---|---|
| Scratch-resistant serving surface | Melamine laminated top resists scuffs from ceramic cups, planters and daily household items, wipes clean with a damp cloth | |
| Open under-table storage | Full-height open space below the tabletop accommodates low storage baskets, footstools or pet beds up to 400 mm tall | |
| Floor protection | Plastic glides at each leg base prevent scratches on tile, vinyl and hardwood flooring, no sharp metal edges contact the floor | |
| Flat-pack assembly | Frame sections connect via pre-drilled holes and included hardware, tabletop attaches to frame with pre-installed threaded inserts | |
| Edge safety design | Rounded 1mm radius tabletop edges eliminate sharp contact points, prevent injury to children and adults during regular use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 1260 x 660 x 110 mm | |
| Gross shipping weight | 22 kg | |
| Shipping volume per unit | 0.09 CBM | |
| assembly time | 30 minutes | |
| 20ft GP container loading quantity | 300 units | |
| 40ft HQ container loading quantity | 720 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm |
Recommended spaces / users / usage modes
| Office reception area use | Place in lounge seating areas in small offices or co-working spaces to serve waiting guests with water cups and reading materials | |
|---|---|---|
| Apartment open plan seating zones | Suitable for compact studio or small apartment seating areas where floor space is limited | |
| Rental property furnishing | Ideal for furnished short-term or long-term rental properties due to durable easy-clean surfaces and simple assembly | |
| Recommended surface accessories | Pair with 4 fabric coasters, a small central planter and a rectangular tray to organize remote controls and small serving items | |
| Casual home living room use | Position in front of fabric or leather sofas in family living rooms for holding drinks, snacks, remote controls and small potted plants |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
| Surface furniture dimensional tolerance recommendation | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Formaldehyde emission recommendation | GB 18584Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based furniture | |
| Metal furniture coating recommendation | GB/T 3325Metal furniture general technical requirements | |
| Furniture surface durability recommendation | GB/T 4893.8Test of surface coatings for furniture - Part 8: Determination of abrasion resistance |
This product must meet the following technical requirements: 1. Surface furniture dimensional tolerance recommendation: GB/T 3324General technical requirements for wooden furniture; 2. Formaldehyde emission recommendation: GB 18584Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based furniture; 3. Metal furniture coating recommendation: GB/T 3325Metal furniture general technical requirements; 4. Furniture surface durability recommendation: GB/T 4893.8Test of surface coatings for furniture - Part 8: Determination of abrasion resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
