Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1400 x 700 x 750 mm | |
|---|---|---|
| Central drawer dimensions | 500 x 400 x 120 mm | |
| Side drawer internal dimensions | 350 x 500 x 150 mm | |
| Seated knee well width | 500 mm | |
| Seated knee well height | 600 mm | |
| Seated knee well depth | 600 mm | |
| Steel top thickness | 25 mm | |
| Body steel panel thickness | 0.8 mm | |
| Foot height | 100 mm | |
| Raised edge lip height | 3 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight range | 55 kg | |
|---|---|---|
| Worktop static load capacity | 100 kg | |
| Recommended user weight tolerance | 150 kg | |
| Drawer slide cycle life | 10000 open/close cycles | |
| Finish abrasion resistance | 2000 cycles | |
| Seating capacity | 1 user | |
| Per drawer static load rating | 25 kg | |
| Stability overturn load | 60 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | Cold-rolled steel sheet with light gray epoxy powder coat finish, rolled safety edge | |
|---|---|---|
| Cabinet body panels | 0.8mm thick cold-rolled steel with matching light gray powder coat | |
| Drawer fronts | 0.7mm thick cold-rolled steel with black outline trim, pre-punched for hardware | |
| Drawer pulls | Injection-molded black plastic recessed pull handles, mounted with two fasteners per handle | |
| Central drawer lock | Brass key-cam lock with steel cylinder, keyed alike default | |
| Drawer slides | Cold-rolled steel 3/4 extension side-mount slides | |
| Integrated support feet | Welded steel tapered feet with leveler-compatible flat base | |
| Internal modesty panel | 0.6mm thick cold-rolled steel panel, finished to match cabinet | |
| Drawer box construction | 0.7mm thick cold-rolled steel drawer boxes, spot-welded corners, powder-coated to match interior | |
| Weld joints | Continuous spot-welded seams on all cabinet frame and pedestal joints, ground smooth before coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Central drawer lock | Key-operated cam lock secures the central middle drawer, prevents unauthorized access to stored contents | |
|---|---|---|
| Left pedestal storage | Three equal-height vertically stacked drawers for general office supply and document storage, operates via independent side-mount slides | |
| Right pedestal storage | Three equal-height vertically stacked drawers for file and supply storage, operates via independent side-mount slides | |
| Central drawer storage | One shallow full-width drawer above knee well for stationery, keyboard accessories or small office items | |
| Work surface function | Flat level work area with rounded rolled edge to eliminate sharp corners and prevent items from sliding off desk edges | |
| Knee well access | Open unobstructed central recess accommodates standard office chairs and seated leg movement for extended work sessions | |
| Surface maintenance | Smooth powder-coated finish allows wipe-clean maintenance with standard office cleaning products, resistant to common office stains and scratches | |
| Central drawer locking | Key-operated cam lock secures the central middle drawer, locks all connected drawers in common 7-drawer desk configurations to prevent unauthorized access to stored contents | |
| Work surface utility | Flat level work area with rounded rolled 3mm edge to eliminate sharp corners and contain small items to prevent sliding off desk edges during use | |
| Cable management | Rear worktop 60mm diameter cable grommet routes monitor and device power cords below work surface, supports up to 3 standard power cables plus peripheral cords | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Shipping carton dimensions | 1450 x 750 x 800 mm | |
| Gross shipping weight | 60 kg | |
| Shipping volume per unit | 0.87 CBM | |
| Assembly time | 15 minutes | |
| 20ft GP container loading quantity | 30 units | |
| 40ft HQ container loading quantity | 75 units | |
| On-site assembly time | 15 minutes | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| General office workspace | Suitable for open-plan offices, administrative staff workstations, and government office environments due to durable steel construction and high storage capacity | |
|---|---|---|
| High-traffic public office areas | Resistant to impact and heavy use compared to wood-composite desks, ideal for service counters, registry offices and public sector work areas | |
| Workshop or industrial office settings | Powder-coated steel surface is resistant to minor heat, spills and abrasion, suitable for use adjacent to production or warehouse areas | |
| Temporary or long-term office fitouts | Fully assembled construction reduces on-site installation time, suitable for rapid office deployment projects | |
| Budget commercial office projects | All-steel construction offers long service life with low maintenance requirements, suitable for cost-sensitive bulk procurement projects | |
| General administrative office workspace | Suitable for open-plan offices, administrative staff workstations, and government office environments due to durable all-steel construction and 7-drawer integrated storage capacity | |
| High-traffic public service areas | Impact-resistant steel construction withstands heavy daily use better than wood-composite desks, ideal for service counters, registry offices and public sector transaction work areas | |
| Industrial adjacent office settings | Chemical-resistant powder-coated steel surface tolerates minor heat, liquid spills and abrasion, suitable for use in production floor offices, warehouse admin stations and workshop work areas |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable European standard for office worktables, dimensional and safety requirements for commercial office desk products | |
|---|---|---|
| EN 527-2:2016 | Applicable European standard for office worktables, mechanical safety and structural performance test methods for commercial desk products |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Applicable standard for furniture desk table dimensional tolerances and stability testing, recommended as acceptance criteria for dimensional accuracy | |
|---|---|---|
| GB/T 4893.1-2021 | Applicable standard for furniture surface film abrasion resistance testing, recommended as acceptance criteria for powder coat finish durability | |
| GB/T 10357.1-2013 | Applicable standard for furniture mechanical performance testing of tables, including static load and stability requirements, recommended as structural acceptance criteria | |
| GB/T 24821-2009 | Applicable standard for steel office furniture general technical requirements, recommended as material and construction quality acceptance criteria |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applicable standard for furniture desk table dimensional tolerances and stability testing, recommended as acceptance criteria for dimensional accuracy; 2. GB/T 4893.1-2021: Applicable standard for furniture surface film abrasion resistance testing, recommended as acceptance criteria for powder coat finish durability; 3. GB/T 10357.1-2013: Applicable standard for furniture mechanical performance testing of tables, including static load and stability requirements, recommended as structural acceptance criteria; 4. GB/T 24821-2009: Applicable standard for steel office furniture general technical requirements, recommended as material and construction quality acceptance criteria; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
