Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 750 mm | |
|---|---|---|
| Work surface thickness | 25 mm | |
| Left pedestal width | 400 mm | |
| Right pedestal width | 400 mm | |
| Center knee clearance width | 400 mm | |
| Knee clearance height under keyboard tray | 620 mm | |
| Keyboard tray usable depth | 350 mm | |
| Lower CPU shelf usable width | 250 mm | |
| Top edge overhang | 20 mm | |
| Cable grommet diameter | 60 mm | |
| Internal cable pass-through diameter | 50 mm | |
| Small drawer internal dimensions (each) | 360 x 500 x 120 mm | |
| Right cabinet door internal usable dimensions | 360 x 500 x 580 mm | |
| Steel panel wall thickness | 0.8 mm | |
| Work surface edge band (rolled edge) thickness | 1.5 mm | |
| Knee clearance depth | 550 mm |
Net weight / load capacity / users / durability
| Product net weight | 52 kg | |
|---|---|---|
| Work surface static load capacity | 150 kg | |
| Recommended user count | 1 | |
| Drawer slide cycle life | 10000 open/close cycles | |
| Surface scratch resistance | 500 rub cycles | |
| Hinge cycle life (cabinet door) | 20000 open/close cycles | |
| Powder coating adhesion rating | Grade 1 | |
| Desk stability tip-over load | 40 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main structural panels | 0.8mm thick cold-rolled steel sheet | |
|---|---|---|
| Surface finish | Epoxy polyester grey powder coating | |
| Drawer pulls | Black ABS plastic recessed handles | |
| Lock cores | Brass keyed lock cylinders | |
| Drawer slides | Cold-rolled steel side-mount 3/4 extension slides | |
| Cable grommets | Grey PVC plastic desk grommets | |
| Internal cable pass-through | Punched round steel hole with de-burred edges | |
| Keyboard tray slides | Cold-rolled steel ball-bearing slides | |
| Desk feet | Welded integrated steel base feet, no separate adjustable glides visible | |
| Cabinet door hinges | Cold-rolled steel butt hinges | |
| Fixed CPU shelf | 0.8mm thick welded cold-rolled steel shelf | |
| Desk base and frame | 1.2mm thick welded cold-rolled steel frame |
Adjustment / rotation / tilt / mobility / storage features
| Left pedestal storage | 3 vertically stacked drawers, top drawer lockable, sized for stationery, documents and small office items | |
|---|---|---|
| Right pedestal storage | 1 top lockable small drawer plus 1 full-height lockable cabinet door with embossed vent grooves, suitable for hanging files and computer tower storage | |
| Pull-out keyboard tray | Center-mounted sliding tray positioned under front work surface, extends fully for keyboard use and retracts flush when not in use | |
| Integrated CPU shelf | Fixed steel shelf located below keyboard tray in center knee cavity, provides dedicated storage space for desktop computer tower | |
| Cable management system | 60mm surface grommet on rear desktop connects to internal 50mm cable pass-through in center cavity, routes power and data cables from desktop devices to lower shelf equipment | |
| Locking function | Keyed lock on left top drawer and right cabinet door, secures stored items from unauthorized access | |
| Work surface edge design | Rounded rolled front and side edges, reduces impact injury risk and prevents sharp edge contact during use | |
| Cabinet ventilation | Embossed horizontal vent grooves on right cabinet door, promote air flow for stored computer equipment to prevent overheating | |
| Fixed CPU shelf | Welded fixed steel shelf located 200mm below keyboard tray in center knee cavity, supports 10kg load for dedicated desktop computer tower storage | |
| Keyboard tray extension lock | Ball-bearing slide detent locks tray in fully extended and retracted positions, prevents unintended sliding during typing or storage | |
| Drawer stop mechanism | Built-in slide stops prevent full accidental drawer pull-out at maximum 3/4 extension, reduces drawer drop and spill risk | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 | |
|---|---|---|
| Carton dimensions | 1280 x 680 x 820 mm | |
| Gross shipping weight | 58 kg | |
| Per-unit shipping volume | 0.72 CBM | |
| On-site assembly time | 10 minutes | |
| 20ft GP container loading capacity | 36 units | |
| 40ft GP container loading capacity | 78 units | |
| Packaging materials | 5-layer corrugated carton, 30mm thick expanded polystyrene corner protection, plastic stretch wrap, plastic bag for keys and hardware | |
| 40ft HQ container loading capacity | 92 units | |
| Stacking limit during storage | 3 units |
Recommended spaces / users / usage modes
| General office open workstations | Suitable for individual staff workstations in corporate offices, government agencies and institutional facilities, provides lockable storage for personal work documents and supplies | |
|---|---|---|
| Public service and administrative offices | Suitable for front desk administrative staff, public service counters and clerical work areas, durable steel surface resists heavy daily use and easy to clean and maintain | |
| Industrial site offices and security rooms | Suitable for factory office spaces, security control rooms and warehouse administrative areas, robust all-steel construction withstands high-traffic, heavy-use environments better than wood-composite desks | |
| Small home office use | Suitable for compact home office spaces, integrated storage eliminates need for separate file cabinets, lockable storage secures personal work materials | |
| Temporary and project site offices | Suitable for construction site temporary offices, project field offices and mobile workspaces, all-steel construction resists damage during relocation and frequent reconfiguration | |
| Computer workstation deployment | Integrated CPU shelf and cable management make this desk ideal for dedicated desktop computer workstations, keeps computer equipment off the floor and organized for IT maintenance | |
| School and educational administrative offices | Suitable for school staff rooms, administrative offices and campus service areas, graffiti-resistant powder coat finish cleans easily and lockable storage secures student records and confidential materials |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable European standard for office work tables and desks: safety requirements, defines stability, strength and dimensional requirements for office work surfaces | |
|---|---|---|
| EN 527-2:2002+A1:2003 | Applicable European standard for office work tables: mechanical safety test methods, defines test procedures for load, durability and stability verification | |
| EN 14073-2:2004 | Applicable European standard for office storage furniture: safety requirements for pedestals and cabinets, defines lock performance, drawer strength and tip-over resistance | |
| EN 1023-2:2000 | Applicable European standard for office storage furniture: test methods for strength and durability of cabinets and pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable standard for office desks and workstations, defines structural performance, durability, stability and surface finish requirements for commercial office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable standard for storage units: pedestals and cabinets, defines drawer cycle performance, load capacity and lock durability for office storage components |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applicable standard for furniture: desks, defines dimensional tolerances, structural strength and stability requirements for office work desks | |
|---|---|---|
| GB/T 24821-2009 | Applicable standard for office furniture: steel office furniture, defines material thickness, coating adhesion, corrosion resistance and load performance requirements | |
| GB 18584-2001 | Applicable standard for indoor decorating and refurbishing materials: limit of harmful substances in wood furniture, applies to any non-steel auxiliary components for formaldehyde and heavy metal limits | |
| GB/T 10357.1-2013 | Applicable standard for furniture mechanical performance test: table strength and stability, defines test methods for desktop load, impact resistance and tip-over stability | |
| GB/T 4893.8-2013 | Applicable standard for furniture surface test: abrasion resistance, defines test method for powder coat surface scratch and rub durability |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applicable standard for furniture: desks, defines dimensional tolerances, structural strength and stability requirements for office work desks; 2. GB/T 24821-2009: Applicable standard for office furniture: steel office furniture, defines material thickness, coating adhesion, corrosion resistance and load performance requirements; 3. GB 18584-2001: Applicable standard for indoor decorating and refurbishing materials: limit of harmful substances in wood furniture, applies to any non-steel auxiliary components for formaldehyde and heavy metal limits; 4. GB/T 10357.1-2013: Applicable standard for furniture mechanical performance test: table strength and stability, defines test methods for desktop load, impact resistance and tip-over stability; 5. GB/T 4893.8-2013: Applicable standard for furniture surface test: abrasion resistance, defines test method for powder coat surface scratch and rub durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
