Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 750 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Seated knee clearance width | 580 mm | |
| Seated knee clearance height | 600 mm | |
| Seated knee clearance depth | 450 mm | |
| Center pencil drawer internal size | 520 x 400 x 100 mm | |
| Right pedestal drawer internal size (per drawer) | 360 x 500 x 150 mm | |
| Support foot height | 100 mm | |
| Desktop overhang (front) | 20 mm | |
| Steel panel thickness (body) | 0.8 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight | 45 kg | |
|---|---|---|
| Desktop static load capacity | 100 kg | |
| Recommended user weight limit | 150 kg | |
| Locking drawer count | 1 | |
| Warranty period | 3 years | |
| Finish abrasion resistance | 5000 rub cycles | |
| Drawer slide cycle life | 50000 cycles | |
| Cam lock cycle life | 10000 cycles | |
| Powder coating abrasion resistance | 5000 rub cycles | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | Cold-rolled steel sheet with epoxy powder coat finish, rolled rounded safety edge | |
|---|---|---|
| Side and frame panels | 0.8mm thick cold-rolled steel, welded box construction | |
| Drawer bodies | Cold-rolled steel formed drawer boxes with integrated slide mounts | |
| Drawer pulls | Injection-molded black PP plastic, recessed ergonomic grip | |
| Center drawer lock | Zinc alloy keyed cam lock with two included keys | |
| Drawer slides | Cold-rolled steel side-mounted 3/4 extension roller slides | |
| Support feet | Welded steel box section feet, powder coated to match frame | |
| Surface coating | Light grey epoxy polyester powder coating, matte finish | |
| Lower knee brace shelf | 0.6mm cold-rolled steel welded between left panel and right pedestal, powder coated to match frame | |
| Left support panel | Full-height 0.8mm cold-rolled steel welded panel extending from floor to desktop underside, forming the left side of the knee bay | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Center drawer locking | Keyed cam lock secures the top center drawer to restrict access to stored stationery and valuables, lock engages when key is turned 90 degrees | |
|---|---|---|
| Drawer extension | Side-mounted roller slides allow 75% extension of all four drawers for easy access to stored contents without tipping risk | |
| Structural support | Full welded left side panel and integrated right pedestal form a rigid box frame that eliminates wobble during writing or typing use | |
| Knee space design | Open knee bay under center drawer accommodates standard armless or t-arm office chairs for seated work, no crossbar obstruction in the primary leg zone | |
| Cable management | Flat desktop surface without pre-drilled cable ports, suitable for surface-mounted cable trays or after-market grommet installation for computer equipment | |
| Leveling stability | Fixed welded feet provide stable placement on flat hard flooring, suitable for after-market adhesive felt pads to protect floor surfaces | |
| Drawer extension travel | Side-mounted roller slides allow 375mm (75%) extension of all four drawers for easy access to rear stored contents without desk tipping risk | |
| Structural rigidity | Full welded left side panel, central knee brace shelf and integrated right pedestal form a rigid closed box frame that eliminates lateral wobble during writing or typing use | |
| Knee space accommodation | Open unobstructed knee bay under center drawer accommodates standard t-arm office chairs up to 560mm wide for seated work, no front crossbar obstruction in the primary leg zone | |
| Cable management compatibility | Flat solid steel desktop without pre-drilled cable ports, supports surface-mounted cable trays or 60mm after-market grommet installation for computer equipment wiring | |
| Pedestal storage organization | Three equal-height stacked right pedestal drawers provide 81L total enclosed storage for documents, office supplies and personal items, sized to fit A4 and letter-size hanging file folders | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 | |
|---|---|---|
| Carton dimensions | 1250 x 650 x 800 mm | |
| Gross shipping weight | 50 kg | |
| Packaging volume (CBM) | 0.65 | |
| Assembly time | 10 minutes | |
| 20ft container loading quantity | 60 units | |
| 40ft HQ container loading quantity | 150 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
Recommended spaces / users / usage modes
| Office workstation use | Suitable for single-person administrative, clerical or reception workstations in government, corporate or small business offices, providing secure drawer storage for daily documents and supplies | |
|---|---|---|
| Temporary workspace use | Suitable for guard posts, factory offices, warehouse admin stations and temporary site offices due to durable scratch-resistant steel construction that withstands high-traffic heavy use | |
| Small home office use | Suitable for compact home office spaces where lockable storage is needed for paperwork and home office supplies, with a small footprint that fits in spare bedrooms or study nooks | |
| Dormitory and institutional use | Suitable for school staff offices, dormitory study desks, and military/ institutional facilities requiring durable, low-maintenance furniture with secure storage | |
| General office workstation use | Suitable for single-person administrative, clerical or reception workstations in government, corporate or small business offices, providing lockable drawer storage for daily documents and supplies | |
| Industrial and site workspace use | Suitable for guard posts, factory floor offices, warehouse admin stations and temporary construction site offices due to durable scratch-resistant steel construction that withstands high-traffic heavy use | |
| Institutional facility use | Suitable for school staff offices, dormitory study desks, and military/institutional facilities requiring durable, low-maintenance furniture with secure storage |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Recommended applicability standard for office work tables - dimensions, applicable to verify work surface height, strength and stability requirements for commercial office use | |
|---|---|---|
| EN 527-2:2016 | Recommended applicability standard for office work tables - safety and strength requirements, applicable to verify desktop load capacity, drawer durability and structural stability |
Standards applicable to China-market projects
| GB/T 3326-2016 | Recommended applicability standard for desk, table and chair furniture dimensions, applicable to verify work surface height, clearance dimensions and drawer size compliance for office use | |
|---|---|---|
| GB/T 3327-2016 | Recommended applicability standard for metal furniture general technical requirements, applicable to verify steel panel thickness, welding quality and coating adhesion requirements | |
| GB 18584-2001 | Recommended applicability standard for indoor decorating and refurbishing materials - limit of harmful substances in furniture, applicable to verify formaldehyde and heavy metal content limits for coating materials |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Recommended applicability standard for desk, table and chair furniture dimensions, applicable to verify work surface height, clearance dimensions and drawer size compliance for office use; 2. GB/T 3327-2016: Recommended applicability standard for metal furniture general technical requirements, applicable to verify steel panel thickness, welding quality and coating adhesion requirements; 3. GB 18584-2001: Recommended applicability standard for indoor decorating and refurbishing materials - limit of harmful substances in furniture, applicable to verify formaldehyde and heavy metal content limits for coating materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
