PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1400 × 700 × 750 mm
Finished Top Thickness	50 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended distributed desktop load	60 kg
Left cabinet top load	40 kg
Modesty panel static load	10 kg
Leveling adjustment	10 mm
Seating capacity	1 person
Net weight	52 kg
Drawer count	0
Suggested service life	8 years
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Desktop	25 mm melamine-faced wood-composite panel with white finish and sealed edge banding
Left side support	White melamine-faced panel case forming a full-height modesty and support side
Modesty panel	White rigid panel suspended beneath the desktop with two gray recessed pull-like inserts
Support legs	Gray powder-coated square steel tube legs with black non-marking end caps
Cable management covers	Gray plastic round grommet and rectangular soft-closing-style access cover
Leveling feet	Black polymer adjustable glides at exposed support points

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Cable routing	Two top cable entries, one 60 mm round grommet and one 300 x 180 mm rectangular access plate, route monitor and power cables below the work surface.
Seated access	An 820 mm wide knee bay is created between the full-height left panel and right metal leg frame for one task chair.
Floor leveling	Adjustable 20 mm glides compensate by 10 mm and keep the desktop stable on uneven office floors.
Privacy screening	A 350 mm deep front modesty panel conceals the user's leg area while retaining side access for chair movement.

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	Main top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight	180 kg/set in 4 cartons
Reference Packaging Volume	1 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Private office workstation	Suits one manager or administrative user requiring cable ports, knee clearance, and a compact 1400 mm footprint.
Open-plan task position	Works in benching clusters or individual cubicles where a white fixed-height desk and privacy panel are specified.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OWS-1400-WHT-CBL

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OWS-1400-WHT-CBL

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OWS-1400-WHT-CBLOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The White Panel-Side Office Workstation presents a clean, structured single-user desk layout with a bright white work surface, a full-height panel support on the left, and gray square metal legs on the right. A white modesty panel is suspended below the front edge, giving the workstation a tailored office appearance while defining the user’s seated zone. The gray cable covers provide discreet visual contrast against the white desktop and panels. Overall dimensions are 1400 x 700 x 750 mm, with a finished top thickness of 50 mm and a 680 mm high, 900 mm wide main knee clearance area. The usable seated opening is 820 mm wide, accommodating one task chair between the left panel and right leg frame. Construction combines melamine-faced wood-composite panels with a steel support system. The desktop uses a 25 mm white melamine-faced wood-composite panel with sealed edge banding. The left support is a white panel case that acts as both a full-height side support and modesty element. The front modesty panel is a rigid white panel fitted with two gray recessed pull-like inserts and rated for a 10 kg static load. Support legs are gray powder-coated square steel tube with an 80 mm main section, 2 mm metal wall, and black non-marking end caps. Black polymer adjustable glides are fitted at exposed support points, providing 10 mm of leveling adjustment for uneven floors. Practical cable management is integrated into the work surface. Two top entries route monitor and power cables below the desktop: a 60 mm round grommet and a 300 x 180 mm rectangular access plate with a gray plastic cover. The cable opening is specified at 80 mm in diameter, with a cable tray depth of 120 mm. The desk is fixed-height and designed for one person, with a recommended distributed desktop load of 60 kg and a 40 kg load rating for the left cabinet top. It includes no drawers, making it best suited to users who prefer open knee space over enclosed storage. This workstation is appropriate for private offices, manager desks, administrative workspaces, open-plan task positions, benching clusters, and individual cubicles where a compact white desk, cable ports, and front privacy screening are required. The 350 mm deep modesty panel conceals the leg area while preserving side access for chair movement. Procurement teams should note the unbranded model OWS-1400-WHT-CBL and plan for assembly, with a reference assembly time of 40 minutes per set. Packaging information varies in the supplied records between a two-carton and four-carton configuration, so shipment details should be confirmed before ordering. The product is listed at 52 kg net weight, while reference packaged gross weight is 180 kg per set and reference packaging volume is 1 m³ per set.

White Panel-Side Office Workstation with Cable Ports and Modesty Panel Specifications
