Automatic mm / inch conversion · Core engineering specifications
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 150 kg | |
|---|---|---|
| Hinge and slide cycle durability | 80000 cycles | |
| Hardware salt spray corrosion resistance | 100 h | |
| Paint surface hardness | 2H | |
| Net product weight | 165 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Recommended maximum user weight for seated use | 136 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Core substrate | 18 mm thick E1-grade high-density fiberboard | |
|---|---|---|
| Surface veneer | 0.6 mm thick natural red-brown cherry wood veneer | |
| Desktop writing pad | 2 mm thick top-grain black leather writing surface | |
| Edge treatment | 8 mm thick matching solid wood edge banding | |
| Paint finish | Multi-coat water-based matte lacquer | |
| Drawer slides | Cold-rolled steel three-section silent full-extension slides | |
| Hinges and locks | Zinc-alloy keyed cam locks and damper soft-close hinges | |
| Cable grommets | Brushed metal cable port with plastic brush insert | |
| Base plinth and support panels | 18 mm thick veneered engineered wood with sealed back panels | |
| Adhesive and sealant | Low-VOC water-based wood adhesive | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Pedestal locking system | Central key lock securing all three left pedestal drawers | |
|---|---|---|
| Cable management | Dual desktop cable grommets routing power and data cables below work surface | |
| Storage configuration | Three utility drawers in left pedestal, one lockable cabinet compartment in right pedestal | |
| Drawer operation | Full-extension soft-close drawers with 450 mm travel, no slam closure | |
| Writing surface | Integrated fixed leather writing pad for comfortable document writing and mouse use | |
| Ergonomic work height | 760 mm working height aligned with standard ergonomic executive chair seat height | |
| Modesty panel | Fixed front modesty panel concealing under-desk knee area for privacy | |
| Leveling adjustment | Threaded anti-slip glides at base corners for uneven floor adjustment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Formal traditional design suitable for director, manager or executive private workspaces | |
|---|---|---|
| Government/state-owned enterprise office | Classic wood-veneer finish aligned with traditional government office furniture specifications | |
| Meeting room leader workstation | Appropriate as a primary work surface in formal meeting or leadership conference spaces | |
| Law firm/financial firm partner office | Premium traditional aesthetic matching professional services formal office decor | |
| Home office executive setup | Suitable for large home offices requiring formal professional work and locked storage | |
| Recommended matching furniture | Pairs with high-back brown leather executive chair and matching lateral filing cabinet for complete office set |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements for commercial office desk construction | |
|---|---|---|
| EN 13722:2004 | Furniture storage units strength and durability requirements for pedestal compartments |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard covering static load, stability and durability for office work surfaces |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to dimensional and structural acceptance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade ≤0.124 mg/m³ required for indoor use | |
| GB/T 4893.4-2013 | Surface paint film abrasion resistance test method for wooden furniture surface durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to dimensional and structural acceptance; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade ≤0.124 mg/m³ required for indoor use; 3. GB/T 4893.4-2013: Surface paint film abrasion resistance test method for wooden furniture surface durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
