Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 800 x 1250 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Minimum seated work surface height | 720 mm | |
| Maximum standing work surface height | 1250 mm | |
| Vertical adjustment stroke | 530 mm | |
| Lifting column cross-section | 80 x 50 mm | |
| Base foot length | 700 mm | |
| Base foot width | 80 mm | |
| Unobstructed knee clearance width at minimum height | 1440 mm | |
| Unobstructed knee clearance depth at minimum height | 700 mm | |
| Control panel dimensions | 120 x 40 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Assembled product net weight | 48 kg | |
|---|---|---|
| Static desktop load capacity | 120 kg | |
| Lifting speed | 38 mm/s | |
| Duty cycle | 10% | |
| Noise level during adjustment | 50 dB | |
| Height adjustment position presets | 4 | |
| Anti-collision sensitivity | 60 N | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Frame finish adhesion rating | Grade 0 | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | 18mm grade P2 particleboard core | |
|---|---|---|
| Desktop surface finish | 0.6mm high-pressure melamine laminate, white top surface with walnut woodgrain edge banding | |
| Lifting column material | 1.5mm thick cold-rolled steel, 3-stage telescoping rectangular profile | |
| Frame and base foot finish | Epoxy-polyester powder coating, matte white | |
| Lifting motor type | 24V DC brush motor, one motor per leg for dual-motor drive | |
| Internal drive mechanism | Steel lead screw drive with self-lubricating polymer bushings | |
| Mounting hardware | Zinc-plated steel M6 bolts and cross dowels | |
| Control panel housing | ABS plastic, matte black finish | |
| Power cord | 1.8m PVC-insulated 3-core power cable, C13 input connector | |
| Adjustable foot pads | Nylon base with steel threaded stem, 10mm adjustment range | |
| Cable grommet | 60mm diameter ABS plastic grommet, walnut finish matching edge banding | |
| Underside cable tray | 0.8mm thick powder-coated steel, 5kg load capacity |
Adjustment / rotation / tilt / mobility / storage features
| Electric height adjustment | Digital button control adjusts work surface between 720mm seated and 1250mm standing height at 38mm/s speed | |
|---|---|---|
| Memory position presets | 4 user-programmable height positions stored via digital handset for one-touch height recall | |
| Dual-motor synchronized operation | Two leg-mounted motors maintain level desktop movement across full adjustment stroke without manual calibration | |
| Anti-collision protection | System automatically reverses direction by 50mm when detecting obstruction during up/down movement to prevent injury or equipment damage | |
| Overheat protection | Control system cuts power to motors after 2 minutes of continuous operation to prevent motor burnout, resets after 18 minutes cooling period | |
| Soft start/stop operation | Motors ramp speed up and down at start and end of travel to reduce jarring and prevent desktop item shifting | |
| Floor leveling adjustment | Threaded foot pads under each base foot compensate for up to 10mm of uneven floor surface | |
| Cable routing channel | Underside frame includes built-in cable management slots for power and data cables, visible cables routed along frame cross members | |
| Integrated cable management | 60mm desktop grommet and 5kg capacity underside steel cable tray route power and data cables to eliminate cord tangles and trip hazards | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 3 | |
|---|---|---|
| Desktop carton dimensions | 1660 x 860 x 80 mm | |
| Frame kit carton dimensions | 820 x 260 x 210 mm | |
| Hardware and accessories carton dimensions | 320 x 200 x 120 mm | |
| Total shipping gross weight | 55 kg | |
| Total shipping volume | 0.19 CBM | |
| assembly time | 45 minutes | |
| 20ft GP container loading quantity | 135 units | |
| 40ft HQ container loading quantity | 350 units | |
| Reference Package Count | 1 set / 2 cartons |
Recommended spaces / users / usage modes
| Open-plan office workstations | Suitable for hot-desking and assigned workspaces, allowing users to switch between seated and standing postures to reduce sedentary fatigue | |
|---|---|---|
| Home office setups | Neutral white and walnut finish fits residential interiors, quiet operation suitable for shared home workspaces | |
| Co-working shared spaces | Durable dual-motor frame supports frequent height adjustment by multiple daily users, programmable presets suit different user heights | |
| Executive private offices | Two-tone desktop finish supports premium office aesthetics, large surface area fits dual monitor setups, keyboard, and work documents | |
| Health-focused workplace programs | Designed to support sit-stand work routines recommended for occupational musculoskeletal health, with height range suited to 95% of adult user heights | |
| Standing meeting areas | Can be set to standing height for short collaborative discussions or quick team meetings without additional seating | |
| Height-accessible workstations | Wide height adjustment range accommodates wheelchair users and users with non-standard seated height requirements for accessible workspace design | |
| Accessible workspaces | 720mm minimum height accommodates wheelchair users with standard knee clearance requirements, no fixed modesty panel allows full forward access |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable European standard for office worktables dimensional, safety and strength requirements | |
|---|---|---|
| EN 527-2:2016 | Applicable European standard for height-adjustable office worktable mechanical safety, durability and stability requirements | |
| EN 1335-2:2009 | Applicable reference standard for ergonomic seating interaction with adjustable-height work surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable standard for desk products covering structural performance, durability, stability and safety requirements for commercial office use | |
|---|---|---|
| ANSI/BIFMA G1-2013 | Applicable ergonomics standard defining recommended work surface height ranges for seated and standing office tasks | |
| ANSI/BIFMA X5.11-2015 | Applicable standard for large-load office desk static and dynamic load capacity testing requirements |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applicable standard for office desk dimensional, structural and stability requirements for general office furniture | |
|---|---|---|
| GB/T 24821-2009 | Applicable standard for office desk desktop surface performance requirements including wear resistance, heat resistance and stain resistance | |
| GB/T 10357.1-2013 | Applicable standard for desk mechanical performance testing including static load, impact and fatigue testing for frame and desktop | |
| GB 18580-2017 | Applicable standard for formaldehyde emission limits for wood-based panel substrates used in indoor office furniture |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applicable standard for office desk dimensional, structural and stability requirements for general office furniture; 2. GB/T 24821-2009: Applicable standard for office desk desktop surface performance requirements including wear resistance, heat resistance and stain resistance; 3. GB/T 10357.1-2013: Applicable standard for desk mechanical performance testing including static load, impact and fatigue testing for frame and desktop; 4. GB 18580-2017: Applicable standard for formaldehyde emission limits for wood-based panel substrates used in indoor office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
