Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1400 x 600 x 720 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Knee clearance height | 680 mm | |
| Leg column cross-section | 60 x 30 mm | |
| Caster diameter | 50 mm | |
| Base spread (front to back per leg) | 580 mm | |
| Tabletop edge thickness | 2 mm | |
| Clearance between base legs (width) | 1100 mm | |
| Under-table clearance from floor to crossbar | 100 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Product net weight | 22 kg | |
|---|---|---|
| Static tabletop load capacity | 100 kg | |
| Caster dynamic load rating per unit | 40 kg | |
| Recommended user capacity | 2 persons | |
| Table tilt lock safety load | 30 kg | |
| Frame static load cycle rating | 10000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 25mm high-density particleboard | |
|---|---|---|
| Tabletop surface | Light beige high-pressure laminate (HPL) | |
| Tabletop edge | 2mm thick PVC edge banding | |
| Support frame and legs | 1.5mm thick cold-rolled steel tube | |
| Tilt pivot joint | Reinforced steel hinge with black plastic end cap | |
| Base feet and casters | TPE dual-wheel swivel casters with steel mounting brackets | |
| Tilt release mechanism | Spring-loaded steel latch with plastic actuator | |
| Surface coating | Epoxy-polyester powder coat | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Tabletop tilt mechanism | 90 degree vertical tilt | |
|---|---|---|
| Caster mobility | 360 degree swivel rotation on all 4 casters | |
| Locking brake | 2 total locking casters | |
| Nesting storage | 100 mm inter-table nesting gap | |
| Height fixed position | 720 mm fixed working height | |
| Edge protection | Rounded impact-resistant edge profile | |
| Leveling function | Caster height adjustment of 5 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of packages | 1 pc | |
|---|---|---|
| Packaging carton dimensions | 1450 x 650 x 120 mm | |
| Packaged gross weight | 25 kg | |
| Packaging volume per unit | 0.113 CBM | |
| Assembly time per unit | 15 minutes | |
| 20ft GP container loading quantity | 230 pcs | |
| 40ft HQ container loading quantity | 560 pcs | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set |
Recommended spaces / users / usage modes
| Corporate training rooms | Suitable for flexible multi-user training setups that require quick reconfiguration between lecture and group work layouts | |
|---|---|---|
| Co-working flexible spaces | Ideal for hot-desking and event spaces where furniture needs to be moved and stored frequently for different events | |
| School classrooms and exam halls | Durable mobile construction supports daily student use and easy rearrangement for different class sizes or exam configurations | |
| Temporary meeting spaces | Can be quickly deployed for pop-up meetings or community events then stored away to free floor space when not in use | |
| Breakout collaboration areas | Lightweight mobile design allows small teams to pull tables together for impromptu collaborative work sessions |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Furniture - Strength, durability and safety requirements for non-domestic tables, applies to commercial training table load and stability testing | |
|---|---|---|
| EN 12529:1998 | Castors for furniture - Castors for office chairs and office furniture, applies to caster rolling performance and brake strength |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to tabletop dimensional stability and edge bonding quality for domestic market supply | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applies to steel frame welding quality and coating adhesion performance | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applies to formaldehyde emission limits for tabletop substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to tabletop dimensional stability and edge bonding quality for domestic market supply; 2. GB/T 3325-2017: Metal furniture general technical requirements, applies to steel frame welding quality and coating adhesion performance; 3. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applies to formaldehyde emission limits for tabletop substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
