Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (WxDxH) | 1200 x 600 x 900 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Tabletop adjustment height range | 720 mm to 900 mm | |
| Leg column outer diameter | 60 mm | |
| Caster diameter | 50 mm | |
| Modesty panel dimensions (WxH) | 1000 x 400 mm | |
| Caster span per base (front to back) | 650 mm | |
| Clearance under table at lowest height setting | 695 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Product net weight | 22 kg | |
|---|---|---|
| Static vertical tabletop load capacity | 50 kg | |
| Maximum recommended user capacity per table | 1 person | |
| Gas lift height adjustment cycle life | 10000 cycles | |
| Tabletop surface horizontal static load deflection | 2 mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 18mm P2 grade particleboard substrate, 2mm PVC edge banding on all sides | |
|---|---|---|
| Tabletop surface finish | 0.6mm light oak woodgrain high-pressure laminate (HPL) | |
| Frame and leg structure | 1.5mm thick cold-rolled steel tube, matte light grey powder coat finish | |
| Height adjustment mechanism | Class 2 gas lift cylinder with black plastic manual adjustment lever | |
| Caster assemblies | TPR soft tread dual-wheel swivel casters with brake, black housing with white wheel | |
| Modesty panel | 15mm matching light woodgrain particleboard panel, hinged to fold with tabletop tilt | |
| Tilt locking hardware | Zinc-plated steel hinge and spring-loaded lock pin | |
| Table underside cross support | 20x40mm rectangular steel cross rail | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Gas-assisted height adjustment | One-handed lever operation adjusts table height from seated 720mm to standing 900mm position, locks automatically when lever is released | |
|---|---|---|
| Tabletop tilting nesting function | Spring-loaded release tilts tabletop 90 degrees to vertical position, enabling compact nested storage between uses | |
| Locking swivel caster mobility | All four casters rotate 360 degrees for easy movement through doorways and between rooms; brake lever locks casters to prevent unintended movement during use | |
| Modesty panel fold function | Hinged modesty panel moves with tabletop tilt, maintaining knee privacy in horizontal use and folding flush against tabletop in vertical storage position | |
| Anti-tip stability design | Three-point splayed leg base distributes weight across 650mm span, preventing tip-over at maximum height and full tilt position | |
| Floor protection function | Soft TPR caster tread will not scratch hard floor surfaces or catch on low-pile carpet fibers, no additional floor mat required for normal office use | |
| Quick reconfiguration capability | No tools required to adjust height, tilt, move or lock the table, enabling full room layout reconfiguration in under 10 minutes per set of tables | |
| Tabletop tilt angle range | 0 to 90 degrees | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Shipping carton dimensions (LxWxH) | 1280 x 680 x 120 mm | |
| Gross shipping weight | 26 kg | |
| Shipping volume per unit | 0.104 CBM | |
| Required assembly time | 20 minutes | |
| 20ft GP container loading quantity | 260 units | |
| 40ft HQ container loading quantity | 630 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set |
Recommended spaces / users / usage modes
| Corporate training rooms | Tables can be quickly reconfigured into rows, groups or nested storage, supporting frequent training layout changes and easy cleaning between sessions | |
|---|---|---|
| Co-working flexible meeting spaces | Height adjustment accommodates seated meetings, stand-up presentations and laptop work for ad-hoc user groups, with mobility to move between zones | |
| Classroom and education environments | Tilting top allows compact storage when not in use, locking casters keep units stable during lessons, durable laminate resists pen marks and impact | |
| Temporary event and exhibition spaces | Lightweight wheeled design enables fast setup and teardown for pop-up meetings, registration desks or presentation stations without permanent installation | |
| Home office flexible workspaces | Compact footprint fits small home offices, adjustable height supports alternating sitting and standing work, casters allow easy relocation between rooms | |
| Healthcare consultation rooms | Smooth laminate surface is easy to disinfect, adjustable height accommodates both wheelchair users and standing staff during patient consultations |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable European standard for office worktables, defining safety, strength and durability requirements for height-adjustable mobile tables | |
|---|---|---|
| EN 1335-2:2009 | Applicable reference standard for caster strength and durability for wheeled office furniture | |
| EN 12521:2015 | Applicable standard for strength, durability and stability of domestic and non-domestic tables used in public and office spaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable standard for desk products, defining static load, cycle, stability and durability test methods for height-adjustable tables | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable standard for storage and mobile furniture components, covering caster durability and braking performance requirements |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applicable standard for dimensions of office tables, applies to desktop height, depth and clearance requirements for this product | |
|---|---|---|
| GB/T 3327-2016 | Applicable standard for mechanical performance and stability requirements for office tables, including static load, deflection and anti-tip testing | |
| GB 18584-2001 | Applicable standard for formaldehyde emission limits for wood-based panel furniture, applies to particleboard tabletop and modesty panel components | |
| GB/T 4893.8-2013 | Applicable standard for surface wear resistance testing of furniture laminate finishes, applies to tabletop durability evaluation |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applicable standard for dimensions of office tables, applies to desktop height, depth and clearance requirements for this product; 2. GB/T 3327-2016: Applicable standard for mechanical performance and stability requirements for office tables, including static load, deflection and anti-tip testing; 3. GB 18584-2001: Applicable standard for formaldehyde emission limits for wood-based panel furniture, applies to particleboard tabletop and modesty panel components; 4. GB/T 4893.8-2013: Applicable standard for surface wear resistance testing of furniture laminate finishes, applies to tabletop durability evaluation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
