| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 700 x 500 x 750 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Steel leg diameter | 38 mm | |
| Under-table knee clearance height | 715 mm | |
| Caster diameter | 50 mm | |
| Frame rail height below tabletop | 10 mm | |
| Leg taper ratio | 0.6 | |
| Nesting clearance when stacked | 80 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Product net weight | 15 kg | |
|---|---|---|
| Uniform tabletop static load capacity | 100 kg | |
| Recommended user capacity | 1 person per unit | |
| Tabletop surface abrasion resistance | 2000 cycles | |
| Steel frame static vertical load | 150 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 18mm particleboard core | |
|---|---|---|
| Tabletop surface | 0.7mm high-pressure laminate (HPL) white finish | |
| Tabletop edge trim | 2mm PVC edge banding, black | |
| Support frame and legs | Grey powder-coated cold-rolled steel | |
| Frame connection hardware | Zinc-plated steel bolts and brackets | |
| Caster wheels | Nylon wheel with TPU tread | |
| Caster stems | 11mm diameter steel grip ring stems | |
| Frame joint collars | Reinforced nylon joint collars | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Mobility function | Four 360-degree swivel dual-wheel casters allow repositioning between room layouts without lifting | |
|---|---|---|
| Nesting configuration | Trapezoidal top shape allows 6 identical units to be arranged into a hexagonal group work table, or nested in linear rows for compact storage | |
| Tabletop work surface | Flat, smooth non-porous surface supports writing, laptop use, and document placement with no built-in tilt mechanism | |
| Floor protection | Non-marking TPU caster tread prevents scuffing on vinyl, carpet, and wood flooring during movement | |
| Stacking storage function | Units can be nested closely together to reduce storage footprint by 70% compared to separate fixed tables | |
| Assembly requirement | Knock-down construction with leg-to-frame bolted connections, no on-site welding or drilling required | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton per unit | |
|---|---|---|
| Shipping carton dimensions | 780 x 580 x 120 mm | |
| Gross shipping weight per unit | 18 kg | |
| Shipping volume per unit | 0.054 CBM | |
| Assembly time per unit | 10 minutes | |
| 20ft GP container loading capacity | 320 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Corporate training rooms | Suitable for flexible corporate training environments where layouts change frequently between lecture, group work, and exam configurations | |
|---|---|---|
| Educational classrooms | Ideal for higher education and vocational school classrooms, supporting both individual study and small group collaborative work | |
| Co-working and event spaces | Appropriate for pop-up events, co-working common areas, and workshop spaces that require quick repositioning of work surfaces | |
| Exam and testing centers | Usable for temporary exam setups, with ability to nest units away when not in use to free floor space | |
| Temporary office setups | Suitable for short-term project offices and temporary workstations that require flexible seating arrangements |
EU Market Access Requirements* EN Standards
| Office furniture safety and stability | EN 527:2002 Office work tables – Safety, strength and durability requirements | |
|---|---|---|
| Office furniture surface durability | EN 14372:2004 Office furniture – Test methods for surface resistance | |
| Caster durability for furniture | EN 12528:1999 Castors and wheels – Castors for furniture |
US and Canada office-furniture standards
| Table load and stability testing | ANSI/BIFMA X2021Desk Products - Tests for safety, durability and structural adequacy | |
|---|---|---|
| Mobile furniture caster testing | ANSI/BIFMA X2017General Purpose Office Chairs - Caster durability test method (applicable to light table casters) |
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB/T 17657E1 grade (≤0.124mg/m³) | |
|---|---|---|
| Furniture structural safety | GB/T 3324General technical requirements for wooden furniture | |
| Metal furniture coating adhesion | GB/T 1993Paint film impact resistance test |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB/T 17657E1 grade (≤0.124mg/m³); 2. Furniture structural safety: GB/T 3324General technical requirements for wooden furniture; 3. Metal furniture coating adhesion: GB/T 1993Paint film impact resistance test; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
