| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 1600 x 600 x 1175 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Caster diameter | 76 mm | |
| Height adjustment stroke | 400 mm | |
| T-base foot length (per leg) | 580 mm | |
| Modesty panel dimensions | 1400 x 400 x 25 mm | |
| Minimum tabletop height (lowest position) | 775 mm | |
| Steel frame tube wall thickness | 1.2 mm | |
| PVC edge band thickness | 2 mm | |
| Nesting storage depth (table top flipped vertical) | 220 mm | |
| Column outer diameter | 80 mm | |
| Knee clearance height (lowest table position) | 745 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Evenly distributed static tabletop load capacity | 161 kg | |
|---|---|---|
| Net product weight | 68 kg | |
| Seating capacity | 4 | |
| Caster dynamic rolling load rating (per caster) | 50 kg | |
| Height adjustment cycle life (pneumatic cylinder) | 10000 cycles | |
| Flip-top hinge cycle life | 5000 cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Powder coating adhesion rating | Grade 1 | |
| Tabletop core substrate moisture content | 11% | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core substrate | E1-grade high-density particleboard | |
|---|---|---|
| Tabletop surface finish | High-pressure white laminate (HPL) | |
| Edge trim | Black PVC T-molding | |
| Height adjustment columns and T-base feet | Light gray epoxy powder-coated steel | |
| Modesty panel | Dark gray rigid steel panel with powder-coated finish | |
| Flip-top hinge hardware | Cold-rolled steel with zinc plating | |
| Caster wheels | Nylon wheel with polyurethane tread, swivel locking design | |
| Pneumatic lift cylinder | Class 3 steel gas cylinder | |
| Assembly fasteners | Zinc-plated steel hex bolts and barrel nuts | |
| Frame bumper pads | 3mm thick TPE rubber pads mounted to contact points for nested table storage | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Pneumatic height adjustment | Side-lever activated stepless height adjustment from 775mm to 1175mm, locks securely at any position within range for seated or standing training use | |
|---|---|---|
| Flip-top nesting function | Spring-assisted side lever releases tabletop to tilt 90 degrees to vertical position, allowing tables to roll into tight nested rows for compact storage when not in use | |
| Caster locking system | Pedal-actuated brake on all four swivel casters, locks both wheel rotation and swivel motion to fix table position during use; releases with pedal lift for reconfiguration | |
| Ganging capability | Integrated linking clip slots on frame sides allow multiple tables to be connected into continuous rows for large conference or exam layouts | |
| Cable management access | Underside modesty panel forms a concealed channel along the long table edge for routing power and data cables between work positions | |
| Tool-less height lock operation | Height adjustment lever operates with light hand pressure, no tools required to change table height during room reconfiguration | |
| Storage stability when nested | Vertical flipped top rests against integrated frame bumpers to prevent surface scratching, nested units can be secured together for bulk storage without tipping | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons per unit | 2 | |
|---|---|---|
| Tabletop carton dimensions | 1650 x 650 x 90 mm | |
| Frame and hardware carton dimensions | 1200 x 320 x 200 mm | |
| Total gross shipping weight per unit | 75 kg | |
| Total shipping volume (CBM) per unit | 0.17 CBM | |
| Required assembly time per unit | 30 minutes | |
| 40ft HQ container loading quantity (knocked down) | 160 units | |
| Interior packaging materials | 5mm thick expanded polystyrene corner protection, PE plastic shrink wrap, cardboard edge protectors | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate training rooms | Ideal for flexible corporate training layouts where tables are frequently reconfigured between lecture, group work, and storage configurations; nestable design reduces storage floor space by 75% when not in use | |
|---|---|---|
| Higher education classrooms and seminar spaces | Suitable for university seminar rooms and exam halls, supporting rapid layout changes between classes; lockable casters prevent movement during exams, height adjustment accommodates accessible seating | |
| Co-working and event spaces | Designed for co-working facilities hosting workshops, meetings and pop-up events, allowing staff to reconfigure room layouts in minutes without heavy lifting; white laminate surface is easy to clean between events | |
| Temporary meeting and overflow work areas | Can be deployed quickly as temporary work or meeting surfaces in office overflow zones, and rolled away to storage when not needed; adjustable height supports both seated laptop work and standing presentation use | |
| Exam and assessment centers | Configurable into individual exam stations or connected rows for written assessments; high-pressure laminate surface resists pen marks and spills for easy cleaning between exam sessions |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 Office work tables - Part 1: Dimensions | Applicable to work surface height, depth, and knee clearance dimension requirements for office and training tables | |
|---|---|---|
| EN 527-2:2002+A1:2019 Office work tables - Part 2: Mechanical safety requirements | Applicable to structural stability, load capacity, and mechanical safety for adjustable height tables | |
| EN 1335-2:2018 (for caster compatibility) | Applicable to caster rolling performance and floor protection requirements matching office chair caster standards for commercial flooring | |
| EN 1728:2012 Furniture - Seating and tables - Test methods for strength and durability | Applicable to cyclic load and durability testing for table hinges, columns, and frame joints |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable to laminate tabletop structural stability, edge bonding quality, and surface finish durability requirements for wooden office furniture | |
|---|---|---|
| GB/T 3325-2017 Metal furniture general technical requirements | Applicable to steel frame/column welding quality, powder coating adhesion, and metal structural strength requirements | |
| GB 28007-2011 Safety of children's furniture (if deployed in K-12 training environments) | Applicable to edge rounding, anti-tip, and hazardous material limits when tables are used for primary/secondary education training rooms | |
| GB/T 10357.1-2013 Furniture mechanical performance test for tables | Applicable to static load, durability, and stability testing for horizontal/vertical table loads | |
| GB 18580-2017 Formaldehyde emission limits for wood-based panels | Applicable to formaldehyde emission testing of particleboard tabletop core substrate |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable to laminate tabletop structural stability, edge bonding quality, and surface finish durability requirements for wooden office furniture; 2. GB/T 3325-2017 Metal furniture general technical requirements: Applicable to steel frame/column welding quality, powder coating adhesion, and metal structural strength requirements; 3. GB 28007-2011 Safety of children's furniture (if deployed in K-12 training environments): Applicable to edge rounding, anti-tip, and hazardous material limits when tables are used for primary/secondary education training rooms; 4. GB/T 10357.1-2013 Furniture mechanical performance test for tables: Applicable to static load, durability, and stability testing for horizontal/vertical table loads; 5. GB 18580-2017 Formaldehyde emission limits for wood-based panels: Applicable to formaldehyde emission testing of particleboard tabletop core substrate; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
