Light Wood Mobile Height-Adjustable Office Desk with Casters and Modesty Panel (model MHAD-LW1200-C) is listed under Flip Top Training Table, with overall dimensions of 1200 × 700 × 1237 mm and main material of Particle‑board (PB). Load capacity: 120 kg. Certifications: mobile,office,furniture,sit-stand,height,adjustment,light,wood,finish,metal,T-leg,base,rolling,caster,full-width,modesty,panel. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions | 1200 x 700 x 1237 mm | |
|---|---|---|
| Desktop thickness | 25 mm | |
| Minimum desktop height | 575 mm | |
| Maximum desktop height | 1237 mm | |
| Height adjustment stroke | 662 mm | |
| Modesty panel dimensions | 1140 x 400 mm | |
| Vertical knee clearance at lowest height | 550 mm | |
| Vertical knee clearance at highest height | 1212 mm | |
| Steel leg column cross-section | 60 x 40 mm | |
| Steel base foot length | 350 mm | |
| Caster diameter | 50 mm | |
| Edge band thickness | 2 mm | |
| Frame wall thickness | 1.5 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 120 kg | |
|---|---|---|
| Lift speed | 40 mm/s | |
| Caster static load rating per wheel | 40 kg | |
| Product net weight | 32 kg | |
| Modesty panel impact resistance | 20 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Recommended user weight capacity | 110 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop | 25mm thick melamine-faced particleboard (MFC) with 2mm PVC edge banding | |
|---|---|---|
| Modesty panel | 18mm thick melamine-faced particleboard matching worktop finish | |
| Frame and leg columns | 1.5mm wall thickness powder-coated light grey steel | |
| Base feet and cross supports | 2mm thick powder-coated light grey steel outriggers | |
| Casters | 50mm diameter black nylon swivel casters, 2 with brake locks | |
| Adjustment hardware | Zinc-plated steel height-locking pins and guide rails |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Height adjustment | Smooth vertical adjustment between seated and standing working heights via side-mounted control | |
|---|---|---|
| Mobility | 360-degree swivel caster movement with 2 lockable brake casters to hold desk position | |
| Privacy screening | Full-width modesty panel blocks under-desk visibility from front view | |
| Cable management | Under-desk horizontal cable tray and desk-top grommet routes power/data cords |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Home office workstation | Compact mobile footprint fits small home workspaces for flexible sit-stand use | |
|---|---|---|
| Open-plan flexible office | Lockable casters enable quick reconfiguration for hot-desking or team meeting setups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables dimensional and safety requirements | |
|---|---|---|
| EN 527-2:2016 | Office worktables mechanical safety and strength test methods |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk products performance and durability test standard | |
|---|---|---|
| ANSI/BIFMA G1-2013 | Height-adjustable desk ergonomic height range requirements |
Standards applicable to China-market projects
| GB/T 3326-2016 | Office furniture desk dimensional and structural stability requirements | |
|---|---|---|
| GB/T 3327-2016 | Office furniture table mechanical performance test standards |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Office furniture desk dimensional and structural stability requirements; 2. GB/T 3327-2016: Office furniture table mechanical performance test standards; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
