Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (L x D x H) | 1200 x 600 x 750 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Evenly distributed static tabletop load capacity | 160 kg | |
|---|---|---|
| Product net weight | 28 kg | |
| Seating capacity per table | 2 people | |
| Caster static load rating per wheel | 40 kg | |
| Flip mechanism cycle life | 10000 operations | |
| Surface scratch resistance rating | 2000 revolutions | |
| Frame static load tip resistance when upright | 15 degrees lateral tilt without tipping | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | E1 grade particleboard core | |
|---|---|---|
| Tabletop surface finish | Light wood tone thermal-fused melamine laminate | |
| Tabletop edge treatment | Matching PVC edge banding | |
| Frame and leg construction | 1.2mm thick cold-rolled steel tubing with white powder-coated finish | |
| Modesty panel | Matching light wood melamine laminated particleboard | |
| Flip pivot mechanism | Stamped steel pivot bracket with zinc-plated locking components | |
| Caster material | Black nylon wheel housing with polyurethane rolling surface and metal brake lever | |
| Frame foot construction | Splayed steel T-feet welded to central vertical column, with caster mounting plates at each foot end | |
| Mounting hardware | Zinc-plated steel screws and connection brackets | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Tabletop flip operation | 90 degree vertical pivot via under-table side lever release | |
|---|---|---|
| Mobility function | Four 360-degree swivel casters, two with locking brakes | |
| Nesting storage capability | Tables nest in tight rows when flipped vertical, reducing storage footprint by 75% compared to fixed tables | |
| Layout reconfiguration | Compatible with side-by-side ganging to form longer conference surfaces | |
| Floor protection | Soft polyurethane caster tread suitable for low-pile office carpet and hard vinyl flooring | |
| Edge impact protection | Rounded PVC edge banding absorbs impact from repeated reconfiguration and contact with chairs | |
| Locking safety function | Dual-position lock secures tabletop in both horizontal work and vertical storage positions | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 2 packages | |
|---|---|---|
| Tabletop package dimensions (L x W x H) | 1260 x 660 x 80 mm | |
| Frame package dimensions (L x W x H) | 780 x 380 x 160 mm | |
| Total shipping gross weight | 33 kg | |
| Total shipping volume (CBM) | 0.11 CBM | |
| Assembly time per unit | 20 minutes | |
| 20ft GP container loading quantity | 260 units | |
| 40ft HQ container loading quantity | 630 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Corporate training rooms | Suitable for high-frequency reconfiguration between training sessions, exams and small group workshops, with quick nesting storage when space is required for other activities | |
|---|---|---|
| Flexible meeting and conference spaces | Can be ganged into longer surfaces for team meetings or separated into individual workstations for breakout sessions, with mobility to adapt to changing meeting sizes | |
| Educational classroom and seminar spaces | Durable laminate surface and stable steel frame support daily student use for lectures, group projects and testing, with easy repositioning for different teaching layouts | |
| Co-working and shared office spaces | Mobile design allows members to rearrange workspaces for individual work, team collaboration or event use without requiring heavy lifting or complex disassembly | |
| Temporary event and pop-up office setups | Locking casters enable fast deployment for temporary events, with compact nested storage when the event concludes to minimize storage space requirements | |
| Compatible chair recommendation | Padded stackable training chairs without armrests, for optimal clearance under the table and efficient storage alongside nested tables between events |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 Office furniture - Work tables and desks - Part 1: Dimensions | Applies to working height, knee clearance and dimensional requirements for office work surfaces including training tables | |
|---|---|---|
| EN 527-2:2002 Office furniture - Work tables and desks - Part 2: Mechanical safety requirements | Applicable standard for structural stability, strength and safety of mobile office tables | |
| EN 1335-3:2009 Office furniture - Office work chair - Part 3: Safety test methods (reference for chair-table clearance compatibility) | Recommended references: EN- | |
| EN 15372:2008 Furniture - Strength, durability and safety - Requirements for non-domestic tables | Applicable standard for commercial non-domestic table load capacity, durability and safety performance |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applies to tabletop panel construction, dimensional tolerance and edge finishing quality requirements for wooden office tables | |
|---|---|---|
| GB/T 3325-2017 Metal furniture general technical requirements | Applies to steel frame welding quality, powder coating adhesion and structural strength requirements for metal table components | |
| GB/T 10357.1-2013 Furniture mechanical performance test for tables | Applicable standard for static load, stability and durability testing of desk and table products for commercial use | |
| GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels | Applicable standards and test results require confirmation |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applies to tabletop panel construction, dimensional tolerance and edge finishing quality requirements for wooden office tables; 2. GB/T 3325-2017 Metal furniture general technical requirements: Applies to steel frame welding quality, powder coating adhesion and structural strength requirements for metal table components; 3. GB/T 10357.1-2013 Furniture mechanical performance test for tables: Applicable standard for static load, stability and durability testing of desk and table products for commercial use; 4. GB 18580-2017 Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wood-based panels: Applicable standards and test results require confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
