Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 900 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net weight per unit | 35 kg | |
|---|---|---|
| Static worksurface load capacity | 150 kg | |
| Seated user capacity | 2 | |
| Nesting storage space saving ratio | 80% | |
| Caster rolling durability | 50000 cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Flip mechanism cycle life | 10000 operations | |
| Frame static load stability rating | 300 kg | |
| Per-side caster static load rating | 50 kg | |
| Melamine surface abrasion resistance | 2000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface | 25mm thick particleboard core with thermal-fused white melamine laminate, scratch and stain resistant finish | |
|---|---|---|
| Tabletop edge trim | 2mm thick black PVC/ABS edge banding, impact-resistant rounded profile | |
| Leg frame and base | 1.5mm thick cold-rolled steel with white high-temperature powder-coated paint-free finish | |
| Modesty panel | 1.2mm thick steel panel with light green powder-coated finish, rounded safety edges | |
| Height adjustment mechanism | Steel pin-lock rotary adjustment dial with numbered height indicators | |
| Flip-top release lever | Stamped steel black powder-coated release trigger under front table edge | |
| Caster wheels | 50mm diameter twin-wheel polyurethane casters with total lock brake, 4 units total (2 per T-foot) | |
| Fasteners and connection hardware | Zinc-plated steel bolts, ganging bracket mounting points pre-drilled on frame sides | |
| Hinge assembly for flip top | Steel friction hinge with positive lock in horizontal use position | |
| Flip hinge assembly | 10mm thick steel friction hinge with positive detent lock in horizontal use position | |
| Ganging hardware points | Pre-drilled 8mm diameter steel mounting points on both frame long sides, with zinc-plated steel connection clips | |
| Adjustment column internal slide | Cold-rolled steel telescoping inner post with nylon wear bushings for smooth height adjustment |
Adjustment / rotation / tilt / mobility / storage features
| Manual height adjustment | 3-position step locking at 720mm, 800mm, 900mm via rotary side dial, no power required | |
|---|---|---|
| Flip-top nesting function | Under-table lever release unlocks tabletop to rotate 90 degrees to vertical position, allowing tables to nest closely in rows for compact storage | |
| Mobile reconfiguration | Four 360-degree swivel casters allow easy rolling by one person, all casters include lock to hold table stationary during use | |
| Multi-table ganging capability | Pre-installed connection points on frame sides allow adjacent tables to be linked into straight or angled conference/ training layouts | |
| Sightline privacy modesty panel | Full-length green panel blocks direct view of user laps and leg movement from front/side, suitable for exam and formal training settings | |
| Impact-resistant edge protection | Rounded black edge trim prevents injury from sharp corners and reduces damage from frequent table movement and contact | |
| Floor protection design | Soft polyurethane caster tread reduces noise and prevents scratching on carpet, hardwood, and vinyl commercial flooring | |
| Flip-top 90-degree nesting | Under-table lever release unlocks hinge to rotate tabletop 90 degrees to vertical position, allowing tables to nest in rows with 120mm gap between units | |
| 360-degree mobile reconfiguration | Four swivel casters allow one-person rolling movement, total lock brakes on all casters lock both wheel rotation and swivel to hold table stationary during use | |
| Multi-table ganging connection | Side-mounted steel clips connect adjacent tables into straight, L-shape or U-shape layouts, eliminating gaps between surfaces during group activities | |
| Floor protection mobility | Soft polyurethane caster tread reduces rolling noise to under 40dB, prevents scratching on carpet, hardwood, and vinyl commercial flooring | |
| Quick tool-free reconfiguration | Flip release and caster brakes operate without tools, allowing full room layout reconfiguration by 1 staff member in 10 minutes for 20 tables |
Verified carton / gross weight / assembly / loading data
| Packaging type | Knock-down flat pack, 1 carton per table | |
|---|---|---|
| Carton dimensions for 1200mm model | 1250 x 650 x 180 mm | |
| Gross weight per carton | 40 kg | |
| CBM per unit | 0.147 CBM | |
| Assembly time per unit | 30 minutes | |
| 20ft GP container loading quantity | 180 units | |
| 40ft HQ container loading quantity | 430 units | |
| Single carton dimensions | 1250 x 650 x 180 mm | |
| Volume per unit | 0.147 CBM | |
| On-site assembly time per unit | 30 minutes |
Recommended spaces / users / usage modes
| Corporate training rooms | Reconfigurable tables can be quickly arranged into rows, groups or U-shapes for instructor-led training, then nested for storage when space is needed for other events | |
|---|---|---|
| Conference and meeting spaces | Multiple tables can be ganged into large conference surfaces for ad-hoc meetings, with height adjustment to support both seated and standing collaboration | |
| Education and exam venues | Smooth writable surface and modesty panel provide privacy for exams and classroom activities, lockable casters keep tables fixed during use | |
| Co-working and event spaces | Lightweight mobile design allows staff to quickly reconfigure space for workshops, pop-up events or temporary workstations without heavy lifting | |
| Healthcare and community centers | Durable easy-clean laminate surface withstands frequent disinfection, stable frame supports accessible use for elderly or mobility-impaired users | |
| Flexible conference spaces | Ganged tables form large continuous conference surfaces for ad-hoc meetings, height adjustment supports both seated discussion and standing presentation use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office furniture - Work tables and desks - Part 1: Dimensions, applicable to worksurface height and clearance requirements for office use | |
|---|---|---|
| EN 527-2:2016 | Office furniture - Work tables and desks - Part 2: Mechanical safety requirements, applicable to frame strength and stability | |
| EN 1725:1998 | Furniture - Tables - Test methods for stability, applicable to tipping resistance testing for mobile tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office Furnishings - Desk Products, applicable to static load, durability, and stability performance requirements for commercial training tables |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate tabletop structural stability and surface finish quality | |
|---|---|---|
| GB/T 3327-2021 | Furniture - Tables and desks, applicable to dimensions, strength, and durability requirements for general office use tables | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable to formaldehyde emission limits for tabletop panel components | |
| GB/T 10357.1-2013 | Test of mechanical properties of furniture - Strength and durability of tables, applicable to static load, impact, and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate tabletop structural stability and surface finish quality; 2. GB/T 3327-2021: Furniture - Tables and desks, applicable to dimensions, strength, and durability requirements for general office use tables; 3. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture, applicable to formaldehyde emission limits for tabletop panel components; 4. GB/T 10357.1-2013: Test of mechanical properties of furniture - Strength and durability of tables, applicable to static load, impact, and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
