Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1220 x 680 x 450 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Lower shelf clearance above floor | 120 mm | |
| Vertical gap between tabletop and lower shelf | 220 mm | |
| Leg cross-section | 50 x 50 mm | |
| Leg wall thickness (solid wood) | 50 mm | |
| Lower shelf thickness | 18 mm | |
| Overhang of tabletop past leg frame | 40 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Tabletop distributed static load capacity | 113 kg | |
|---|---|---|
| Net product weight | 25 kg | |
| Recommended maximum number of users served | 5 | |
| Surface finish abrasion resistance | 400 cycles | |
| Finish moisture resistance rating | Level 2 for general lounge use | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop panel | Solid hardwood with matte brown stain finish | |
|---|---|---|
| Legs | Solid tapered hardwood with matching brown finish | |
| Lower storage shelf | Solid hardwood panel, fixed between leg supports | |
| Structural connectors | Zinc-plated steel wood screws and cross dowels | |
| Surface finish | Clear matte polyurethane sealer | |
| Edge treatment | Rounded 3mm eased edge on tabletop and shelf | |
| Frame stretchers | Solid wood cross rails connecting legs at shelf level | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Tabletop surface function | Flat fixed surface for drink service, decor and light reading material | |
|---|---|---|
| Lower storage function | Open full-width shelf for magazines, remotes or decorative items | |
| Assembly requirement | Knockdown assembly with leg and shelf attachment to top | |
| Floor protection | Plastic glides fitted to bottom of each leg | |
| Structural rigidity | Fixed mortise and reinforced screw joint construction | |
| Surface maintenance | Wipe-clean sealed surface compatible with standard wood cleaners | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Office executive lounge placement | Positioned in front of leather sofa seating groups for guest reception | |
|---|---|---|
| Living room residential use | Centered between sofas and armchairs for casual family and guest use | |
| Reception area waiting zone | Used as center table in corporate waiting areas with lounge seating | |
| Hotel suite lounge area | Placed in guest room seating nooks for drink service and reading material | |
| Recommended pairing configuration | Matched with 3-seat sofa and two single armchairs as full lounge set |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic tables, applicable for load and stability verification | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface finishes, applicable for abrasion and moisture resistance validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional stability and structural safety checks | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional stability and structural safety checks; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
