Automatic mm / inch conversion · Core engineering specifications
| Overall 3-seat sofa dimensions | 2050 x 850 x 880 mm | |
|---|---|---|
| Single armchair dimensions per unit | 920 x 820 x 880 mm | |
| Seat height from floor | 420 mm | |
| Seat depth (usable surface) | 580 mm | |
| Backrest total height | 460 mm | |
| Armrest height from seat surface | 200 mm | |
| Wooden arm cap width | 120 mm | |
| Center coffee table dimensions | 1200 x 600 x 450 mm | |
| Side end table dimensions | 600 x 600 x 500 mm | |
| Support leg height for sofas | 120 mm | |
| Coffee table lower shelf clearance | 220 mm | |
| Seat cushion thickness | 120 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Set total weight (all pieces) | 185 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Recommended maximum occupancy | 5 persons | |
| Foam density for seat cushions | 40 kg/m³ | |
| Foam density for back cushions | 30 kg/m³ | |
| Seam stitch tensile strength | 80 N | |
| Upholstery abrasion resistance | 50000 cycles | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | |
| Per-seat Load Reference | 130 kg/seat |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery material | Black 1.0mm thick matte faux leather (PU leather) | |
|---|---|---|
| Wood trim components | Polished solid hardwood with cherry red-brown lacquer finish | |
| Internal seating frame | 30mm thick engineered hardwood and plywood frame | |
| Seat cushion core | High-resilience polyurethane foam with 10mm soft foam top layer | |
| Back cushion core | Medium-density polyurethane foam | |
| Table top material | 18mm thick medium-density fiberboard (MDF) with cherry wood veneer finish | |
| Sofa support legs | Turned solid hardwood legs with polished lacquer finish | |
| Lower coffee table shelf | 15mm thick MDF with matching cherry wood veneer | |
| Upholstery stitching | Nylon-bonded thread with 8mm stitch pitch | |
| Floor protection pads | 5mm thick non-marking rubber pads | |
| Seat support system | 80mm wide sinuous steel springs with 50mm spacing | |
| Table frame joinery | Dowel and hardware-reinforced solid wood frame for tables |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed modular arrangement: 1 three-seat sofa + 2 single armchairs + 1 center coffee table + 1 side end table | |
|---|---|---|
| Cushion design | Fixed attached seat and back cushions | |
| Coffee table storage | Open fixed lower shelf for magazine and small item storage | |
| Backrest support | Segmented triple-panel backrest with lumbar support zone | |
| Surface maintenance | Stain-resistant wipe-clean upholstery and wood finishes | |
| Stability design | Four-point wide leg placement for all seating and table pieces | |
| Armrest function | Wide flat wood arm caps for temporary placement of small items | |
| Seat suspension response | Sinuous spring suspension with 20% compression deflection under rated load | |
| Cushion Service Configuration | Recommended 2 removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Total shipping cartons | 7 cartons | |
|---|---|---|
| Largest carton dimensions (3-seat sofa) | 2100 x 900 x 650 mm | |
| Total gross shipping weight | 220 kg | |
| Total shipment volume | 2.9 CBM | |
| On-site assembly time | 90 minutes | |
| 20ft GP container loading quantity | 28 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item |
Recommended spaces / users / usage modes
| Corporate executive reception areas | Formal traditional styling with wood trim and black upholstery, suitable for greeting business visitors in company headquarters and executive floor waiting zones | |
|---|---|---|
| Government and institution meeting waiting rooms | Conservative professional appearance, durable construction suitable for high-traffic public waiting areas in office buildings, public institutions and administrative facilities | |
| Private office lounge zones | Scaled to fit small lounge areas within executive private offices, providing casual seating for short meetings or visitor waiting | |
| Bank and financial service customer areas | Stain-resistant easy-to-clean surfaces and formal aesthetic suited for customer waiting spaces in bank branches, insurance offices and financial service centers | |
| Recommended pairing | Coordinate with matching dark wood office furniture, neutral tone carpet or hard flooring, minimal wall decor to maintain a professional uncluttered reception appearance | |
| Formal business guest rooms | Suitable for seating in hospitality suites or business guest rooms where a professional, durable and low-maintenance seating set is required | |
| Law firm and professional service waiting spaces | Formal understated design aligns with professional service brand presentation, durable for daily use by visiting clients |
EU Market Access Requirements* EN Standards
| EN 13759:2001 | Domestic and contract furniture – Seating – Test methods for determination of structural durability, applicable for cyclic load testing of sofa frames and joints for commercial use | |
|---|---|---|
| EN 1022:2005 | Domestic furniture – Seating – Determination of stability, applicable for verifying anti-tip stability of single chairs and three-seat sofa under normal use | |
| EN 15372:2008 | Furniture – Strength, durability and safety – Requirements for non-domestic tables, applicable for load and stability testing of coffee and side tables for office reception use | |
| EN 14465:2003 | Furniture – Upholstery fabrics – Specification for minimum performance requirements, applicable for abrasion, color fastness and tear strength of PU upholstery material |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Standard for Lounge Seating, applicable for commercial office reception seating, covering static load, durability, stability and dimensional performance criteria | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Standard for Desk Products, applicable for performance and safety requirements of the included wood coffee and side tables used in office environments |
Standards applicable to China-market projects
| GB/T 3324-2017 | Wooden furniture – General technical requirements, applicable for wooden trim, table components and frame finish quality, formaldehyde emission limits and surface durability | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials – Limit of harmful substances of wood based furniture, mandatory requirement for formaldehyde and heavy metal content for all wood-based components | |
| GB/T 16799-2008 | Polyurethane coated fabrics for furniture, applicable for performance requirements of the PU leather upholstery including abrasion resistance, color fastness and flexibility |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Wooden furniture – General technical requirements, applicable for wooden trim, table components and frame finish quality, formaldehyde emission limits and surface durability; 2. GB 18584-2001: Indoor decorating and refurbishing materials – Limit of harmful substances of wood based furniture, mandatory requirement for formaldehyde and heavy metal content for all wood-based components; 3. GB/T 16799-2008: Polyurethane coated fabrics for furniture, applicable for performance requirements of the PU leather upholstery including abrasion resistance, color fastness and flexibility; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
