| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall 3-seat sofa dimensions | 2200 x 850 x 900 mm | |
|---|---|---|
| Overall single armchair dimensions | 1100 x 850 x 900 mm | |
| Seat height from floor | 450 mm | |
| Seat depth for 3-seat sofa | 580 mm | |
| Seat cushion thickness | 120 mm | |
| Backrest height above seat | 450 mm | |
| Armrest height above seat | 200 mm | |
| Arm width at widest trim point | 120 mm | |
| Total set footprint (arranged as shown) | 3400 x 2200 mm | |
| Clearance under sofa frame | 60 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
| Total set gross weight | 200 kg | |
|---|---|---|
| Per-seat static load capacity | 150 kg | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Recommended maximum occupancy | 5 persons | |
| Seam stitching pitch | 8 stitches per 30mm | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Manufacturing warranty | 5 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery cover | 1.2mm thick dark brown PU leather with semi-aniline finish | |
|---|---|---|
| Arm and foot trim | Polished red-toned solid hardwood with clear lacquer topcoat | |
| Internal frame | 40mm thick kiln-dried solid wood and hardwood plywood frame | |
| Seat support system | 3.8mm diameter sinuous S-springs spaced 100mm apart | |
| Cushion filling | High-density polyurethane foam with polyester fiber wrap | |
| Backrest filling | 35kg/m³ density polyurethane foam with soft fiber topper | |
| Frame hardware | Zinc-plated steel corner brackets and wood screws | |
| Foot pads | Non-marking rubber foot glides | |
| Stitching thread | Bonded polyester upholstery thread | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed 1 three-seat sofa + 2 single armchair set layout | |
|---|---|---|
| Recline function | Fixed upright non-reclining backrests | |
| Assembly requirement | Minimal assembly requiring only foot attachment to pre-built frames | |
| Cleaning compatibility | Surface-wipeable leather upholstery suitable for commercial disinfectants | |
| Floor protection | Non-marking rubber glides on all feet | |
| Weight distribution | Evenly distributed spring and frame support prevents cushion sag | |
| Arrangement flexibility | Freestanding units can be repositioned to fit varying reception room layouts | |
| Wooden block foot height | 60 mm | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
| Corporate reception lobbies | Formal styling projects professional image for visiting clients and guests | |
|---|---|---|
| Executive office waiting areas | Complements dark wood executive furniture in CEO/manager office spaces | |
| Boardroom ancillary seating | Provides overflow seating adjacent to conference tables for long meetings | |
| Public institution waiting rooms | Durable easy-clean upholstery suitable for high-traffic government or bank spaces | |
| Hotel business centers | Matches formal hospitality decor for guest work and meeting areas | |
| Recommended complementary furniture | Dark wood coffee table placed centrally between seating units for guest convenience |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Office furniture seating safety requirements, applicable to static load and stability testing | |
|---|---|---|
| EN 1022:2018 | Domestic and contract seating stability test standard for non-tipping verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2021 | Lounge and public seating standard for static load, durability, and stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood trim and frame components | |
|---|---|---|
| GB/T 19001-2016 | Quality management system reference for production consistency of commercial furniture | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, recommended formaldehyde emission limit of 0.124mg/m³ |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to solid wood trim and frame components; 2. GB/T 19001-2016: Quality management system reference for production consistency of commercial furniture; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, recommended formaldehyde emission limit of 0.124mg/m³; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
