Automatic mm / inch conversion · Core engineering specifications
| Finished Seat Cushion Thickness | 90 mm | |
|---|---|---|
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 175 kg | |
|---|---|---|
| Per-seat static load capacity | 180 kg | |
| Single chair swivel mechanism static load rating | 160 kg | |
| Cushion foam density | 45 kg/m³ | |
| Seating capacity for full set | 5 people | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 0.9mm thick dark gray top-grain match faux leather | |
|---|---|---|
| Internal cushion core | 45kg/m³ high-resilience polyurethane foam | |
| Sofa support frame | 1.5mm thick powder-coated square steel tubing | |
| Single chair swivel base | Matte black powder-coated 4-star steel frame, 2mm wall thickness | |
| Coffee table top | 12mm thick matte black sintered stone surface | |
| Coffee table support structure | Matte black powder-coated steel spider legs, 1.8mm wall thickness | |
| Armrest padding | 20mm thick high-density foam wrapped in matching upholstery | |
| Backrest internal support | 12mm thick multilayer hardwood plywood panel | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Single armchair swivel function | 360-degree smooth rotation on sealed bearing base, no tilt or recline | |
|---|---|---|
| Fixed sofa configuration | Stationary non-swivel design with angled fixed metal legs | |
| Integrated wide padded armrests | Fixed armrests on all seating units for forearm support during extended seating | |
| Low-profile coffee table design | Fixed height surface centered between seats for beverage, document and decor placement | |
| Stitched seam construction | 8mm stitch pitch on all upholstery seams for reinforced wear resistance | |
| Leveling foot adjustment | Small adjustable floor glides on all legs to compensate for uneven flooring | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Executive office reception area | Formal seating for meeting guests outside private executive offices, professional dark finish | |
|---|---|---|
| Corporate lounge waiting space | Durable commercial-grade construction for high-traffic employee or visitor waiting areas | |
| High-end meeting breakout zone | Comfortable seating for informal small group discussions outside formal conference rooms | |
| Luxury home office space | Premium dark aesthetic matches modern residential executive office design schemes | |
| Boardroom ancillary seating | Positioned adjacent to formal board tables for pre-meeting guest waiting | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 13759:2003 | Applicable test standard for safety and strength of office seating | |
|---|---|---|
| EN 1022:2018 | Applicable standard for stability of domestic and contract seating | |
| EN 15372:2016 | Applicable standard for strength, durability and safety of office tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Applicable performance standard for lounge and public area seating | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Applicable performance standard for desk and occasional table products |
Standards applicable to China-market projects
| GB 18584-2001 | Applicable standard for limit of harmful substances in wooden furniture components | |
|---|---|---|
| GB/T 3324-2017 | Applicable general technical requirements for metal furniture structural performance |
This product must meet the following technical requirements: 1. GB 18584-2001: Applicable standard for limit of harmful substances in wooden furniture components; 2. GB/T 3324-2017: Applicable general technical requirements for metal furniture structural performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
