Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 870 × 940 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Solid wood plinth base height | 50 mm | |
| Seat cushion depth | 585 mm | |
| Armrest height from seat | 220 mm | |
| Backrest total height from seat | 490 mm | |
| Seat cushion thickness | 150 mm | |
| Matching coffee table dimensions | 1200 x 600 x 500 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| 3-seater sofa total static load capacity | 500 kg | |
|---|---|---|
| Seat foam density | 55 kg/m³ | |
| Seat foam rebound rate | 60% | |
| Seat foam compression set | 5% | |
| Back foam density | 35 kg/m³ | |
| Upholstery color fastness grade | 4 | |
| Seam stitch density | 4 stitches per cm | |
| Total set net weight | 260 kg | |
| Standard warranty period | 60 months | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Upholstery surface | 1.6mm thick burgundy top-grain leather | |
|---|---|---|
| Internal structural frame | 12mm thick hot-pressed formed board and dried hardwood | |
| Armrest and base trim | Polished solid red-toned wood with clear lacquer finish | |
| Seat cushion fill | High-resilience polyurethane foam | |
| Back cushion fill | Medium-density polyurethane foam | |
| Seat support system | 30mm diameter serpentine springs with elastic webbing | |
| Base floor contact | Non-slip polymer floor glides | |
| Frame joinery | Mortise and screw reinforced connections | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | 1 three-seat sofa plus 2 matching single armchairs | |
|---|---|---|
| Seating mechanism | Fixed static non-reclining structure | |
| Floor protection | Integrated glides under wood plinth base | |
| Matched furniture compatibility | Pre-sized for matching 1200x600mm coffee table and 600x600mm side table | |
| Upholstery maintenance | Smooth non-porous leather surface | |
| Assembly requirement | Knock-down partial assembly for transport | |
| Color customization | Burgundy standard, with black and brown options available | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive office reception areas | Formal styling suitable for welcoming corporate guests and visitors | |
|---|---|---|
| Government and institutional meeting waiting rooms | Durable commercial construction meets public area use requirements | |
| Business negotiation spaces | U-shaped layout supports face-to-face conversation between hosts and guests | |
| Hotel lobby executive lounges | Coordinated formal aesthetic matches premium public space interiors | |
| Corporate boardroom anterooms | Neat structured design complements formal boardroom furnishing schemes | |
| High-end enterprise entrance waiting zones | Stain-resistant leather finish withstands regular high-traffic use |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 13759:2008 | Applicable domestic furniture seating safety test method for structural stability | |
|---|---|---|
| EN 1022:2018 | Applicable seating stability test standard for domestic and contract seating |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2024 | Applicable standard for wooden furniture general technical requirements, for wood trim components | |
|---|---|---|
| GB 18580-2017 | Applicable formaldehyde emission limit, E0 grade for wood-based frame materials | |
| GB 18401-2010 Class B | Applicable safety standard for leather and textile direct contact surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2024: Applicable standard for wooden furniture general technical requirements, for wood trim components; 2. GB 18580-2017: Applicable formaldehyde emission limit, E0 grade for wood-based frame materials; 3. GB 18401-2010 Class B: Applicable safety standard for leather and textile direct contact surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
