Automatic mm / inch conversion · Core engineering specifications
| Full set overall footprint | 3200 x 2600 x 750 mm | |
|---|---|---|
| Single lounge armchair dimensions | 780 x 820 x 750 mm | |
| Two-seat rear sofa unit dimensions | 1800 x 820 x 750 mm | |
| Integrated middle side table (rear sofa) | 450 x 450 x 600 mm | |
| Central coffee table dimensions | 1200 x 700 x 450 mm | |
| Lounge seat height from floor | 450 mm | |
| Seat depth for all seating units | 580 mm | |
| Armrest height from seat surface | 180 mm | |
| Backrest height above seat surface | 300 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Single seat static load capacity | 160 kg | |
|---|---|---|
| Total set net weight | 180 kg | |
| Recommended maximum concurrent users | 4 people | |
| Padding foam density | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Swivel mechanism cycle rating | 30000 rotations | |
| Commercial use warranty period | 5 years | |
| Available standard upholstery colors | 5 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back internal frame | 25mm thick kiln-dried solid hardwood | |
|---|---|---|
| Seat and back padding | 45kg/m³ high-resilience polyurethane foam | |
| Seating upholstery | 1.2mm thick PU faux leather, abrasion resistance 50000 cycles | |
| Armrest pads | Padded faux leather matching seat upholstery, steel support structure | |
| Swivel base construction | 15mm thick powder-coated matte black steel spider frame | |
| Central coffee table top | 10mm thick matte dark grey tempered glass | |
| Coffee table legs | 12mm diameter powder-coated black steel hairpin legs | |
| Integrated side table top | Matte light grey engineered stone, 20mm thickness | |
| Floor glides | Non-marking nylon glides on all base feet | |
| Upholstery base layer | 100g/m² non-woven fabric backing under upholstery | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Swivel seat operation | 360-degree smooth rotation with automatic return to center | |
|---|---|---|
| Modular configuration support | Units can be repositioned to alter lounge layout for different spaces | |
| Integrated side table function | Built-in flat surface between rear sofa seats for beverage or device placement | |
| Central coffee table function | Low central surface for shared refreshments, reading materials and decor | |
| Non-tilting seat design | Fixed pitch seat with no recline or tilt adjustment for formal reception use | |
| Floor protection feature | Nylon glides prevent scratching polished stone or hard office flooring | |
| Upholstery maintenance | Stain-resistant wipe-clean surface for high-traffic reception areas | |
| Swivel base diameter (all seating) | 680 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Executive office waiting zones | Provides formal guest seating outside private executive offices | |
|---|---|---|
| Corporate reception lobbies | Creates a professional welcoming area for visiting clients and guests | |
| Office breakout collaboration areas | Supports small informal team meetings or short break sessions | |
| High-end open plan office common areas | Complements modern open workspaces without visual clutter | |
| Commercial showroom waiting areas | Provides comfortable seating for customers during sales consultations | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 13761:2002 | Office furniture — Visitor chairs, applicable to lounge seating strength and stability | |
|---|---|---|
| EN 1022:2018 | Domestic and contract furniture — Seating — Determination of stability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge Seating standard, applies to structural durability and load testing | |
|---|---|---|
| ANSI/BIFMA X7.1-2011 | Standard for low-emitting office furniture, applies to indoor air quality |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal frame construction | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, required for indoor office use | |
| GB/T 19001-2016 | Quality management system requirement for commercial furniture manufacturing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal frame construction; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, required for indoor office use; 3. GB/T 19001-2016: Quality management system requirement for commercial furniture manufacturing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
