Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 500 x 580 x 940 mm | |
|---|---|---|
| Seat surface width | 380 mm | |
| Seat surface depth | 390 mm | |
| Maximum seat height from floor | 550 mm | |
| Minimum seat height from floor | 430 mm | |
| Backrest total height | 410 mm | |
| Armrest height above seat | 180 mm | |
| Footrest platform height from floor | 180 mm | |
| Five-star caster base diameter | 520 mm | |
| Crotch safety tab height above seat | 40 mm | |
| Caster wheel diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 11 kg | |
|---|---|---|
| Maximum static user weight capacity | 113 kg | |
| Recommended user age range | 13 years | |
| Recommended user height range | 1600 mm | |
| Seat cushion foam density | 40 kg/m³ | |
| Seat cushion foam thickness | 60 mm | |
| Fabric abrasion resistance | 30000 cycles | |
| Foam rebound rate | 60% | |
| Seam stitch pitch | 8 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Backrest upholstery | Breathable textured mesh | |
|---|---|---|
| Seat upholstery | Abrasion-resistant woven mesh | |
| Seat and back cushion core | High-density polyurethane foam | |
| Seat and back support frame | Glass-fiber reinforced polypropylene | |
| Armrest pads | Soft TPU padded surface | |
| Height adjustment gas lift | Carbon steel class 2 gas cylinder | |
| Five-star base and footrest ring | Reinforced nylon composite | |
| Caster wheels | Soft TPU tread with nylon hub | |
| Armrest support brackets | Reinforced engineering plastic | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seat height adjustment | 120 mm vertical travel via gas lift | |
|---|---|---|
| Backrest dynamic support | 25° backward tilt with tension adjustment | |
| Seat rotation function | 360° full swivel | |
| Caster safety lock | Gravity-activated brake at 30 kg load | |
| Anti-tip stability design | Wide circular footrest ring integrated with base | |
| Forward slide prevention | Raised front crotch tab on seat pan | |
| Foot support function | Integrated wide foot platform around lift column | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Home study space | Paired with height-adjustable children's desks for homework, reading and art activities | |
|---|---|---|
| Classroom or training center | Used in early education centers and tutoring spaces for students 13 years old | |
| Shared family work areas | Suitable for multi-child households where chair height needs frequent adjustment | |
| Hard floor environments | Soft TPU casters prevent scratches on wood, tile and laminate flooring | |
| Long study sessions | Breathable mesh and contoured padding reduce fatigue during 2 hour seated tasks | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Children's furniture safety | EN 1729:2015 | |
|---|---|---|
| Furniture mechanical stability | EN 1022:2018 | |
| Upholstered furniture flammability | EN 1021:2014 |
Standards applicable to China-market projects
| Chair structural safety | GB 28007 | |
|---|---|---|
| Upholstered furniture durability | GB/T 3324 | |
| Harmful substance limits | GB 18584 |
This product must meet the following technical requirements: 1. Chair structural safety: GB 28007; 2. Upholstered furniture durability: GB/T 3324; 3. Harmful substance limits: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
