Name: Modern Low-Profile Light Gray L-Shaped Sectional Sofa with Right Chaise
Brand: Youwei
SKU: 73A79X

Time

Field

Original Value

Corrected Value

Note / Status

No correction records yet. Found an error? Click the flag at the end of a row to report it.

PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	4250 × 1630 × 860 mm
Seat height	500 mm
Seat depth (main section)	710 mm
Chaise lounge width	1100 mm
Chaise lounge depth	1630 mm
Armrest height	660 mm
Back cushion height	450 mm
Seat cushion thickness	180 mm
Ground clearance	50 mm
Single seat module width	950 mm
Back Cushion Thickness	160 mm
Leg Height / Floor Clearance	160 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total static load capacity	450 kg
Seat cushion foam density	45 kg/m³
Back cushion fill density	28 kg/m³
Fabric abrasion resistance	50000 double rubs
Seat foam rebound rate	60%
Frame static load durability	50000 cycles
Seat Foam Density / Rebound	40 kg/m³ / 60%
Upholstery Abrasion Reference	Fabric 60000 cycles; leather-class cover 1.4 mm
Per-seat Load Reference	130 kg/seat
Upholstery Seam Pitch	4 mm

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Inner frame	Kiln-dried solid pine wood with mortise-and-tenon reinforcement
Upholstery fabric	Matte light gray 320g/m² performance fabric (tech cloth)
Seat cushion core	High-resilience polyurethane foam wrapped in 20mm soft down blend
Back cushion fill	Blown polyester fiber and down blend for soft layered support
Armrest structure	Curved padded wood frame wrapped in foam and matching upholstery
Base support feet	Hidden matte black ABS low feet with non-slip pads
Seat support system	80mm wide sinuous steel springs with 50mm spacing
Stitching detail	Reinforced polyester thread with 30mm seam pitch
Timber Frame Section / Moisture	Primary section ≥30 × 50 mm; recommended moisture 12%
Spring / Webbing Specification	Sinuous spring wire 4 mm; elastic webbing 70 mm wide
Leg Connector Specification	Reference M8-M10 with at least 1 mechanical fixing per leg
Reference Upholstery Color Count	Recommended 8fabric/leather color options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Chaise configuration	Fixed right-side chaise lounge for extended leg rest
Cushion design	Loose, reversible seat and back cushions for even wear
Armrest function	Padded curved armrests on both ends provide arm support and side visual balance
Cleaning access	Zippered removable cushion covers for spot cleaning or washing
Modular connection	Heavy-duty metal bracket connectors hold seating modules firmly aligned
Floor protection	Non-slip rubber pads on bottom feet prevent floor scratches and sliding
Orientation option	Right-chaise layout as shown, factory customizable to left chaise
Cushion Service Configuration	Recommended 2removable/replaceable cushion methods

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Module Carton Dimensions	2200× 1050× 850 mm
Reference Packaging Volume	1.8 m³/item
Reference Packaged Gross Weight	110 kg/item

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Large open-plan living room	Fits 35m²+ living spaces as primary lounge seating facing media or coffee table
Modern minimalist residential interior	Matches low-profile neutral gray aesthetic for contemporary, light luxury home design
5-person household seating	Accommodates 4 adults on main section plus 1 reclining on chaise for daily use
High-end apartment lounge	Suitable for furnished luxury residential units with floor-to-ceiling window layouts
Quiet lounge zone	Deep cushions support extended relaxed sitting for reading, conversation or media viewing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 12520:2015	Domestic furniture strength, durability and safety requirements for upholstered seating
EN 1021-1:2014	Upholstered furniture ignition resistance to smouldering cigarettes for fire safety

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to inner frame and structural components
GB 18584-2001	Limit of harmful substances in wooden furniture, for formaldehyde emission control verification
GB/T 1952.1-2012	Test methods for upholstered sofas, applicable to strength and durability acceptance

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to inner frame and structural components;
2. GB 18584-2001: Limit of harmful substances in wooden furniture, for formaldehyde emission control verification;
3. GB/T 1952.1-2012: Test methods for upholstered sofas, applicable to strength and durability acceptance;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LSEC-RCH-4250-LGRY

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LSEC-RCH-4250-LGRY

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LSEC-RCH-4250-LGRYOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Youwei model LSEC-RCH-4250-LGRY is a modern, minimalist low-profile L-shaped sectional sofa featuring a fixed right chaise, finished in matte light gray performance tech fabric for a streamlined, uncluttered visual presence. Its balanced layout includes padded curved armrests at both ends to deliver even visual weight and cohesive silhouette, paired with loose, reversible seat and back cushions that lend a relaxed, inviting aesthetic without compromising tailored lines. The design sits on hidden matte black ABS low feet, creating a subtle, grounded profile that complements unobtrusive contemporary interior schemes. Constructed for long-term regular use, the sofa’s inner frame uses kiln-dried solid pine wood with mortise-and-tenon reinforcement, built to a primary timber section size of 30 × 50 mm with a recommended 12% moisture content for structural stability. Seat support comes from 80mm wide sinuous steel springs spaced 50mm apart, while seat cushions hold a high-resilience polyurethane core wrapped in 20mm soft down blend, topped with 180mm thick cushioning with 45 kg/m³ foam density and 60% rebound rate. Back cushions are filled with a blown polyester fiber and down blend for soft, layered support, and curved padded wood armrests are wrapped in foam and matching upholstery. The 320g/m² matte tech fabric delivers 50000 double rubs of abrasion resistance, with reinforced polyester thread stitching set to a 30mm seam pitch for durable seams. Hidden feet include non-slip rubber pads to protect flooring. Practical functions are tailored to everyday residential use: the fixed right chaise offers extended leg rest space, while loose reversible cushions promote even wear over time. Zippered removable cushion covers allow straightforward spot cleaning or washing, and heavy-duty metal bracket connectors hold seating modules firmly in aligned position. The total static load capacity reaches 450 kg, with frame static load durability tested to 50000 cycles. The factory can customize the orientation to a left-side chaise for alternate layout needs. Overall dimensions measure 4250 x 1630 x 860 mm, with a 500mm seat height, 710mm main section seat depth, 1100mm chaise width, 1630mm chaise depth, 660mm armrest height, and 450mm back cushion height. This sofa is sized to accommodate 4 adults across the main section plus 1 person reclining on the chaise, suitable for 5-person households. It is ideal for large open-plan living rooms of 35m² and above as primary lounge seating positioned facing a media unit or coffee table, fits seamlessly into modern minimalist residential interiors with neutral-toned, light luxury design schemes, works well in high-end furnished apartment lounges adjacent to floor-to-ceiling windows, and creates a comfortable quiet lounge zone for reading, casual conversation, or media viewing. For procurement, note the model is delivered as 1 set across 2 cartons, with a packaged gross weight of 110 kg, 1.8 m³ packaging volume, and a reference assembly time of 40 minutes per set. Buyers should confirm preferred chaise orientation prior to order placement to match site layout requirements, and account for access clearances to accommodate the largest module carton dimensions of 2200× 1050× 850 mm during delivery and installation planning.

Modern Low-Profile Light Gray L-Shaped Sectional Sofa with Right Chaise Specifications
