Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1800 × 980 × 890 mm | |
|---|---|---|
| seat height from floor | 430 mm | |
| seat depth per cushion | 590 mm | |
| back cushion height | 320 mm | |
| armrest width | 200 mm | |
| armrest height above seat | 150 mm | |
| seat cushion thickness | 170 mm | |
| back cushion thickness | 120 mm | |
| ground clearance under base | 20 mm | |
| single seat module width | 700 mm | |
| Leg Height / Floor Clearance | 160 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| gross weight | 64 kg | |
|---|---|---|
| static load per seat | 160 kg | |
| total static load capacity | 320 kg | |
| seat foam density | 30 kg/m³ | |
| fabric abrasion resistance | 30000 cycles | |
| foam rebound rate | 60% | |
| seam stitch pitch | 8 stitches per inch | |
| warranty period | 2 years | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| frame construction | Kiln-dried solid wood and plywood composite frame | |
|---|---|---|
| upholstery fabric | Dark brown 300g/m² polyester tech fabric | |
| seat cushion fill | High-density polyurethane foam with polyester fiber wrap | |
| back cushion fill | Blended high-density foam and polyester fiber fill | |
| support webbing | 50mm wide elastic webbing suspension under seats | |
| armrest structure | Padded wood frame wrapped in matching upholstery | |
| base construction | Upholstered block base with concealed plastic glides | |
| upholstery backing | Non-woven fabric dust cover under base | |
| fabric finish | Stain-repellent easy-clean surface treatment | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| seat configuration | Two individual fixed box seat cushions aligned in straight layout | |
|---|---|---|
| back configuration | Two matching fixed box back cushions aligned with seat units | |
| armrest design | Integrated padded square armrests on both ends of the sofa | |
| cushion cover design | Non-removable sewn upholstery covers | |
| modular connection | Hidden metal bracket join between two seat modules | |
| floor protection | Concealed non-marking glides under base corners | |
| seating orientation | Fixed front-facing linear seating for two users | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential living room | Suitable for small to medium apartment living rooms as primary seating | |
|---|---|---|
| home lounge and reading area | Ideal for casual relaxation with deep cushioned seats and low back support | |
| modern minimalist interior schemes | Matches monochrome and neutral contemporary decor with clean block silhouette | |
| secondary seating for home office reception | Appropriate for informal guest seating in home office reception zones | |
| studio apartment open-plan layouts | Fits compact open-plan living spaces without blocking sightlines |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Furniture - Assessment of ignitability of upholstered furniture (smouldering cigarette) |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame construction | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 1952.1-2012 | Test methods for sofas, applicable to seating performance and durability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame construction; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 3. GB/T 1952.1-2012: Test methods for sofas, applicable to seating performance and durability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
