Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 780 x 760 x 820 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended user weight | 140 kg | |
|---|---|---|
| Static frame verification load | 420 kg | |
| Net weight | 15 kg | |
| Seating capacity | 1 person | |
| Backrest rearward angle | 105 degrees from horizontal | |
| Seat foam thickness | 100 mm | |
| Back foam thickness | 60 mm | |
| Fabric Martindale abrasion target | 50,000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery | Grey woven textile with a dense mixed-yarn appearance | |
|---|---|---|
| Back upholstery | Matching grey woven fabric over a curved padded back panel | |
| Arm pads | Fabric-covered padded sleeves fitted over the horizontal metal arm rails | |
| Metal frame | Black round-tube steel frame forming arm supports, legs, and side perimeter | |
| Frame finish | Matt black powder-coated surface with smooth continuous bends | |
| Internal seat support | Rigid plywood or molded composite seat board with elastic webbing support | |
| Cushion filling | High-resilience polyurethane foam with a soft polyester fiber top layer | |
| Back filling | 45 kg/m3 polyurethane foam pad with fabric-laminated finish | |
| Floor contact tips | Small black polymer glides at all four exposed leg ends | |
| Joining hardware | Welded tube joints with bolted upholstered body connections | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Arm support | Continuous tubular side frame provides left and right arm support at 210 mm above the seat | |
|---|---|---|
| Back support | Tall curved back wraps around the upper body and provides shoulder-height lateral enclosure | |
| Seating posture | Fixed relaxed lounge angle with a 420 mm seat height and 105-degree back inclination | |
| Mobility | Static four-point chair design with polymer glides; no casters or swivel mechanism are present | |
| Arm pad comfort | Each metal arm rail includes a 260 mm padded fabric sleeve to reduce forearm contact pressure | |
| Floor protection | Hard polymer end caps isolate the metal legs from hard floors and allow light repositioning | |
| Cleaning access | Open frame underneath permits broom or vacuum access below the 250 mm floor clearance | |
| Assembly method | Knockdown frame-to-body attachment with four primary fasteners is the expected delivery method | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office lounge | Suitable for employee relaxation zones and informal touchdown areas with one-person seating per unit | |
|---|---|---|
| Reception area | Appropriate for waiting areas where visitors need a soft seat, back support, and arm support | |
| Hotel lobby | Can be used in pairs beside a coffee table in lobby or guest-corner layouts | |
| Co-working space | Suitable for breakout zones, quiet corners, and informal conversation seating | |
| Senior living lounge | Usable in assisted lounges where a 420 mm seat and integrated arms aid sit-down support | |
| Residential living room | Can serve as an accent chair in a living room, study, or bedroom reading corner | |
| Cafe waiting zone | Suitable for premium cafe seating where a relaxed lounge posture is desired | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
