| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 950 W x 864 D x 953 H mm | |
|---|---|---|
| Seat width | 760 mm | |
| Seat depth | 560 mm | |
| Seat height | 470 mm | |
| Backrest height | 570 mm | |
| Armrest height from seat | 210 mm | |
| Armrest width | 130 mm | |
| Seat cushion thickness | 140 mm | |
| Under-seat clearance | 210 mm | |
| Four-star base diameter | 820 mm | |
| Base rail section | 30 x 20 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended user weight | 125 kg | |
|---|---|---|
| Chair net weight | 27.9 kg | |
| Seat cushion foam density | 45 kg/m3 | |
| Back padding foam density | 35 kg/m3 | |
| Foam rebound rating | 45% | |
| Swivel bearing durability | 100,000 cycles | |
| Base static load rating | 375 kg | |
| Upholstery abrasion rating | 50,000 Martindale cycles | |
| Color options | 2 colors | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Caramel full-grain leather or corrected leather cover | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam, 140 mm thick | |
| Back padding | Moulded polyurethane pad with fibre wadding | |
| Inner seat shell | Steel seat frame with S-shaped spring support | |
| Back support board | 12 mm bent plywood or composite board inside upholstered shell | |
| Four-star base | Black powder-coated steel cross frame with four floor-contacting legs | |
| Swivel mechanism | Central steel turntable bearing between seat frame and cross base | |
| Arm shell structure | Upholstered rigid continuous shell integrating arms and back | |
| Seam detail | Tonal stitched perimeter with black piping at shell joints | |
| Floor contacts | Integrated black non-marking polymer glides at each leg tip | |
| Under-seat support plate | 3 mm powder-coated steel adapter plate | |
| Surface finish | Low-sheen black coating on exposed metal base |
Adjustment / rotation / tilt / mobility / storage features
| Swivel motion | 360-degree horizontal rotation around a fixed central bearing | |
|---|---|---|
| Return behavior | Free-rotation non-return mechanism with neutral seating position | |
| Back support | Fixed reclined lounge back providing continuous shoulder and lumbar contact | |
| Arm support | Wraparound fixed arms support forearms and visually enclose the seat | |
| Seat cushion | Removable boxed seat cushion with hidden perimeter seam | |
| Floor protection | Four non-marking glides allow rotation without scratching hard floors | |
| Rocking or recline | No powered recline, tilt lock, or rocking mechanism identified | |
| Height adjustment | No gas-lift height adjustment; seat remains at 470 mm | |
| Occupancy configuration | Single-occupant seating with side-arm boundaries and one central cushion | |
| Backrest recline angle | 108 degrees from horizontal | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Carton dimensions | 970 x 900 x 750 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Living room reading area | Pairs with a side table and floor lamp for relaxed reading | |
|---|---|---|
| Hotel lounge or guestroom corner | Provides a compact swivel seat without casters for upscale interiors | |
| Executive reception space | Fits quiet conversation zones beside low tables or feature walls | |
| Residential study or bedroom corner | Supports laptop-free relaxation and phone calls outside a task chair | |
| Boutique waiting area | Can be used individually or in spaced pairs for visitors | |
| Design-focused showroom display | Suitable for material, lighting, and contemporary furniture displays | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
Open Export Tool
