Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 820 x 680 x 830 mm | |
|---|---|---|
| Seat width | 570 mm | |
| Seat depth | 570 mm | |
| Seat height | 490 mm | |
| Back height above seat | 340 mm | |
| Integrated arm/side height | 610 mm from floor | |
| Under-seat ground clearance | 180 mm | |
| Front apron height | 120 mm | |
| Leg projection and splay | Front legs splay outward 45 mm from vertical | |
| Leg cross-section | 42 x 42 mm at the upper joint | |
| Footprint between front feet | 610 mm center-to-center | |
| Turning clearance radius | 760 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight | 21.1 kg | |
|---|---|---|
| Recommended user load | 150 kg | |
| Seating capacity | 1 person | |
| Seat foam density | 35 kg/m3 | |
| Seat foam thickness | 140 mm thick compressed cushion | |
| Back padding thickness | 80 mm | |
| Back resting angle | 102 degrees from horizontal | |
| Fabric abrasion acceptance target | 30,000 Martindale cycles | |
| Seam stitch pitch | 8 stitches per 50 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | Dark gray-green textured woven boucle-style fabric | |
|---|---|---|
| Seat cushion | Removable-looking fabric-covered foam pad over flexible support | |
| Back and side shell | Continuously upholstered curved wood or engineered-panel shell | |
| Internal frame | Kiln-dried hardwood or engineered wood frame with 25 mm nominal members | |
| Legs | Dark-stained solid hardwood tapered splayed legs | |
| Floor contacts | Rigid polymer or felt glide pads at each leg foot | |
| Seat support deck | Elastic webbing or sinuous spring deck beneath foam | |
| Back padding | Flexible polyurethane foam laminated to curved shell | |
| Fabric backing | Woven textile backing with flame-retardant treatment available by order | |
| Leg finish | Dark espresso-toned stained or lacquered wood surface | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating posture | Fixed relaxed lounge posture with 102-degree back pitch and no recline travel | |
|---|---|---|
| Back support | Continuous semicircular shell wraps laterally to provide shoulder and upper-arm enclosure | |
| Arm support | Integrated upholstered side panels provide arm-height support without adjustable arm pads | |
| Swivel function | None; chair remains stationary on four fixed wood legs | |
| Rocking function | None; straight tapered legs provide a stable fixed footprint | |
| Mobility | Lift-and-reposition chair by frame; no casters installed | |
| Cushion serviceability | Thick seat cushion may be upholstered as lift-out or fixed deck-attached unit | |
| Floor protection | Four individual glide pads spread load and reduce hard-floor scratching | |
| Assembly method | Legs attach to tapped corner plates with supplied hardware during final assembly | |
| Cleaning access | Low open base permits vacuuming under the seat with 180 mm ground clearance | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Living room reading corner | Placed as a single lounge seat beside a side table and floor lamp | |
|---|---|---|
| Bedroom dressing area | Used near a wardrobe or window for occasional seating and putting on footwear | |
| Hotel guest room | Specified in pairs or as one accent chair near a window or desk area | |
| Reception waiting area | Used in small groupings in boutique offices and lounges | |
| Retail showroom display | Positioned as an accent piece in furniture displays or lifestyle vignettes | |
| Senior living common room | Suitable for light-duration seating where soft side enclosure is preferred | |
| Residential study | Paired with a 550 mm side table for short breaks and conversation | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| Stability standard | EN 1022 applies to seating stability verification for domestic and contract use. | |
|---|---|---|
| Strength and durability standard | EN 16139 applies to non-domestic seating strength and durability where specified. |
US and Canada office-furniture standards
| Seating structural suitability | ANSI/BIFMA X5.4 applies when lounge seating is specified for commercial interiors. | |
|---|---|---|
| Static and cyclic load verification | ANSI/BIFMA X5.4 back, seat, leg and durability tests support contract procurement acceptance. | |
| Floor-protection component review | Caster/glide tests under ANSI/BIFMA X5.9 can be applied to leg glide durability requirements. |
Standards applicable to China-market projects
| Structural safety reference | GB/T 10357.2 applies to chair back and rear leg static strength acceptance testing. | |
|---|---|---|
| Seat and front stability reference | GB/T 10357.3 applies to chair seat and front static loading. | |
| Durability test reference | GB/T 10357.7 applies to repeated chair impact and fatigue evaluation. | |
| Upholstered furniture flammability review | GB 17927 applies to upholstered furniture burning behavior for China-market orders. |
This product must meet the following technical requirements: 1. Structural safety reference: GB/T 10357.2 applies to chair back and rear leg static strength acceptance testing.; 2. Seat and front stability reference: GB/T 10357.3 applies to chair seat and front static loading.; 3. Durability test reference: GB/T 10357.7 applies to repeated chair impact and fatigue evaluation.; 4. Upholstered furniture flammability review: GB 17927 applies to upholstered furniture burning behavior for China-market orders.; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
