Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Seat Cushion Thickness | 90 mm | |
|---|---|---|
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 14 kg | |
|---|---|---|
| Recommended occupant load | 136 kg | |
| Static seat proof load | 340 kg | |
| Backrest proof load | 113 kg | |
| Arm downward proof load | 68 kg per side | |
| Seat foam density | 35 kg/m3 | |
| Back foam density | 28 kg/m3 | |
| Foam ball rebound | 35% | |
| Fabric Martindale abrasion | 50000 cycles | |
| Color options visible | 3 colors |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer upholstery | Boucle-style woven textile over the entire back, arms, and side panels | |
|---|---|---|
| Seat upholstery | Matching woven fabric over a padded fixed seat cushion | |
| Inner structural shell | 18 mm plywood or engineered-wood bent panels | |
| Internal support frame | 25 mm square hardwood or steel reinforcing frame | |
| Seat cushion core | 100 mm polyurethane foam with a 20 mm soft top layer | |
| Back padding | 30 mm polyurethane foam bonded to the curved inner shell | |
| Arm padding | 20 mm foam layer over rigid side panels | |
| Seat support board | 12 mm bent plywood or composite panel | |
| Underside dust cover | Black non-woven polyester fabric | |
| Floor protectors | 4 concealed polymer glides with felt contact faces | |
| Fabric seam construction | Sewn cover with a center-back vertical seam and blind-edge tacking | |
| Surface finish | Matte textured fabric with no exposed metal or wood finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lounge posture | Fixed 100-degree relaxed sitting angle formed by the curved back and 430 mm seat height | |
|---|---|---|
| Wraparound support | Continuous back and arm shell encloses the user on three sides for lateral support | |
| Fixed cushion design | The seat is secured within the shell and is not designed to rotate, recline, or swivel | |
| Integrated armrests | The two tall side panels act as arms at 650 mm above floor and connect into the floor-supported base | |
| Side cutouts | Open cutouts beneath the seat reduce visual weight and assist handling without exposing a frame | |
| Floor protection | Four non-marking glides allow repositioning on tile, wood, or low-pile carpet | |
| Stacking capability | Non-stackable fixed sculptural chair, intended for individual placement | |
| Cleaning access | Smooth continuous upholstery allows vacuuming and spot cleaning around the front and side openings | |
| Seam alignment requirement | The center-back seam should align vertically within 2 mm after upholstery | |
| Color coordination | Single-tone upholstery covers the shell, seat, arms, and inner back for a monochromatic appearance | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Lobby waiting area | Use as individual guest seating with 900 mm circulation gaps around the 740 mm wide shell | |
|---|---|---|
| Hotel lounge | Pair two chairs with a 450 mm side table for conversation settings | |
| Office breakout space | Deploy in small groups for informal meetings or short-duration relaxation | |
| Retail showroom | Use colored versions as sculptural display seating in boutique fitting or rest areas | |
| Residential living room | Place one chair beside a window, sofa, or side table in apartments and lounges | |
| Senior living common room | Specify with firm 35 kg/m3 foam and non-marking glides for short-stay resident seating | |
| Cafe social corner | Use in low-traffic premium cafes where a fixed lounge posture and decorative fabric are desired | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| Furniture strength and durability for seating | EN 16139:2013 applies to strength, durability, and stability for non-domestic seating | |
|---|---|---|
| Upholstered furniture safety | EN 1022:2018 applies to seating stability tests |
US and Canada office-furniture standards
| Lounge seating safety and durability | ANSI/BIFMA X2022applies to lounge seating strength, durability, and stability | |
|---|---|---|
| Low-emission furniture | ANSI/BIFMA e2019applies if the project requires furniture chemical-emission credits |
Standards applicable to China-market projects
| Furniture mechanical safety | GB 28007applies to stability, edge safety, and structural integrity for household furniture | |
|---|---|---|
| Upholstered furniture burning behavior | GB 17927applies when domestic flame-retardant performance is contractually required | |
| Formaldehyde emission | GB 18580applies to formaldehyde control for engineered-wood components |
This product must meet the following technical requirements: 1. Furniture mechanical safety: GB 28007applies to stability, edge safety, and structural integrity for household furniture; 2. Upholstered furniture burning behavior: GB 17927applies when domestic flame-retardant performance is contractually required; 3. Formaldehyde emission: GB 18580applies to formaldehyde control for engineered-wood components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
