Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 750 x 600 x 985 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Front plinth base height | 100 mm | |
| Raised front panel count | 6 panels | |
| Chamfered end bevel angle | 45 degrees | |
| Desktop working surface height | 760 mm | |
| Under-desk knee clearance height | 660 mm | |
| Under-desk knee clearance depth | 450 mm | |
| Control panel width (right top) | 120 mm | |
| Paired chair backrest height | 1160 mm | |
| Paired chair seat width | 550 mm | |
| Paired chair seat height | 450 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Total unit net weight | 85 kg | |
| Hardware salt spray corrosion resistance | Grade 10 after 180h acetic acid test | |
| Wood frame moisture content | 10% | |
| Seat foam compression set | 4% | |
| Seat foam rebound rate | 40% | |
| Finish VOC content | 30 g/L | |
| Product warranty period | 10 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 0.6mm red-brown wood veneer over 45mm MDF core, scratch-resistant matte polyurethane topcoat | |
|---|---|---|
| Front facade panels | Raised recessed engineered wood panels with solid hardwood edge molding | |
| Base plinth | Solid hardwood molded stepped plinth with matching veneer wrap | |
| Internal frame | Reinforced square steel tube internal support frame | |
| Paired chair frame | Solid hardwood frame with carved finial posts on backrest | |
| Chair upholstery | Tufted black faux leather surface with button detailing, high-density flame-retardant foam padding |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated AV control interface | Right-top mounted button array for microphone, evidence display and audio system control | |
|---|---|---|
| Cable management system | Concealed internal cable channels with desktop pass-through grommets for AV and power wiring | |
| Leveling adjustment | Adjustable hidden leveling feet on base bottom for uneven courtroom floor alignment | |
| Seating configuration | Centered fixed witness seating position aligned to desk center, no casters or swivel function |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Suitable space | Courtrooms, arbitration chambers and formal hearing rooms for witness testimony | |
|---|---|---|
| Recommended configuration | Paired with dedicated AV, microphone and evidence display systems |
EU Market Access Requirements* EN Standards
| EN 13722:2004 | Strength and durability requirements applicable to office and institutional desks | |
|---|---|---|
| EN 16139:2013 | Strength, durability and stability requirements for non-domestic seating | |
| EN 717-1:2004 | Formaldehyde emission testing method applicable to wood-based panel components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Safety and performance standard applicable to institutional desk products | |
|---|---|---|
| ANSI/BIFMA X5.4-2012 | Safety and performance standard applicable to institutional lounge/guest seating |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to wooden general furniture products | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit applicable to interior wooden furniture materials | |
| GB/T 19995.1-2005 | Water-based wood finish performance requirements for wooden furniture surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to wooden general furniture products; 2. GB 18584-2001: Formaldehyde emission limit applicable to interior wooden furniture materials; 3. GB/T 19995.1-2005: Water-based wood finish performance requirements for wooden furniture surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
