Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 2400 x 1000 x 760 mm | |
|---|---|---|
| Desktop panel thickness | 50 mm | |
| Edge banding thickness | 2 mm | |
| Seated knee clearance height | 660 mm | |
| Front base panel thickness | 25 mm | |
| Raised panel frame width | 60 mm | |
| Angled corner cut length per side | 150 mm | |
| Cable grommet diameter | 80 mm | |
| Integrated control panel width | 120 mm | |
| Base plinth height | 80 mm | |
| Desktop overhang front | 30 mm | |
| Center drawer front width | 400 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide dynamic load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Finish abrasion resistance | 2000 cycles | |
| Net weight (desk only) | 180 kg | |
| Maximum supported user weight with equipment | 200 kg | |
| Surface flatness tolerance | 0.006 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | 0.6 mm imported natural wood veneer | |
|---|---|---|
| Core substrate | E1-grade high-density fiberboard | |
| Surface finish | 8-coat polyurethane lacquer (5 primer, 3 topcoat) | |
| Base panel frames | Solid hardwood trim | |
| Hardware components | Premium branded drawer slides and hinges | |
| Cable management components | ABS plastic grommets and steel cable tray |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable management | Dual desktop grommets + under-desk steel tray | |
|---|---|---|
| Central lockable storage | Keyed central lock secures all drawers and cabinet doors | |
| Embedded control panel | Right-side desktop panel houses power/USB/data ports | |
| Modest panel privacy | Full-height enclosed front base blocks view of under-desk area |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive office | Formal traditional aesthetic matches C-suite and senior management workspaces | |
|---|---|---|
| Government/institutional office | Conservative reddish wood finish suitable for formal public sector environments |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, safety and strength requirements | |
|---|---|---|
| EN 12521:2015 | Furniture - Strength, durability and safety requirements for domestic and office tables |
Standards applicable to China-market projects
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of formaldehyde emission for wood furniture | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture, dimensional and structural integrity |
This product must meet the following technical requirements: 1. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of formaldehyde emission for wood furniture; 2. GB/T 3324-2017: General technical requirements for wooden furniture, dimensional and structural integrity; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
