Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall bench dimensions | 4500 x 950 x 900 mm | |
|---|---|---|
| Chief judge chair dimensions | 680 x 600 x 1700 mm | |
| Associate judge chair dimensions | 680 x 600 x 1600 mm | |
| Work surface height above floor | 760 mm | |
| Seated knee well height | 620 mm | |
| Seated knee well depth | 600 mm | |
| Front panel pilaster width | 80 mm | |
| Carved judicial emblem diameter | 300 mm | |
| Chair backrest height above seat | 1100 mm | |
| Chair seat height above floor | 450 mm | |
| Chair seat depth | 500 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Bench total static load capacity | 450 kg | |
|---|---|---|
| Bench net weight | 250 kg | |
| Wood component moisture content | 12% | |
| Seat foam density | 35 kg/m³ | |
| Backrest foam density | 30 kg/m³ | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg | |
| Caster Rolling Durability Reference | Acceptance target 30000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Bench frame and trim | Solid hardwood with mortise-and-tenon joinery | |
|---|---|---|
| Bench panel substrate | E1 grade MDF with 0.6mm natural mahogany wood veneer | |
| Finish coating | 7-coat matte polyester paint (4 primer, 3 topcoat) | |
| Chair upholstery | 1.5mm thick first-grade top-grain cowhide, black tufted design | |
| Chair internal frame | Solid hardwood mortise-and-tenon frame | |
| Leveling feet | Steel with rubber base, adjustable height |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating configuration | 1 chief judge position (center) + 2 associate judge positions (sides) | |
|---|---|---|
| Cable management | Recessed under-desk cable trough with desktop grommets | |
| Front modesty panel | Fully enclosed raised panel facade with carved central judicial emblem | |
| Assembly structure | Knockdown bolted assembly with reinforced connecting brackets |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Standard courtrooms | Formal trial settings requiring official judicial emblem and traditional wood finish | |
|---|---|---|
| Hearing rooms and arbitration venues | Formal adjudication spaces requiring durable, authoritative judicial furniture |
EU Market Access Requirements* EN Standards
| EN 1335-2:2009 | Office furniture - Office work chairs - Safety requirements | |
|---|---|---|
| EN 14073-2:2004 | Office furniture - Storage furniture - Safety requirements | |
| EN 71-3:2019 | Toy safety - Migration of certain elements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Office Chairs - General purpose | |
|---|---|---|
| ANSI/BIFMA X5.5-2021 | Desk Products - Performance and test requirements |
Standards applicable to China-market projects
| GB 18581-2020 | Indoor decoration and refurbishment solvent-based wood coatings limit of harmful substances | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels for indoor use | |
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
| GB/T 16799-2008 | General technical requirements for furniture leather |
This product must meet the following technical requirements: 1. GB 18581-2020: Indoor decoration and refurbishment solvent-based wood coatings limit of harmful substances; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels for indoor use; 3. GB/T 3324-2017: General technical requirements for wooden furniture; 4. GB/T 16799-2008: General technical requirements for furniture leather; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
