Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Per 4-seat bench module overall dimensions | 2400 x 850 x 1080 mm | |
|---|---|---|
| Individual seat center width | 600 mm | |
| Seat surface height above local tier floor | 460 mm | |
| Seat usable depth | 480 mm | |
| Backrest total height above seat surface | 620 mm | |
| Armrest height above seat surface | 260 mm | |
| Inter-row riser height between tiers | 300 mm | |
| Clear row spacing (seat back to front seat back) | 1100 mm | |
| Under-seat storage cubby internal height | 320 mm | |
| Under-seat storage cubby depth | 420 mm | |
| Wood panel thickness for seat and back | 18 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-seat static load capacity | 250 kg | |
|---|---|---|
| Unit net weight per 4-seat bench module | 128 kg | |
| Total seating capacity per 3-row dual bank set | 24 seats | |
| Finish abrasion resistance | 10000 cycles | |
| Installation pull-out load per floor anchor | 8 kN | |
| Structural service life | 15 years | |
| Warranty period for structural components | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Seat and back panels | 18mm hardwood plywood with reddish brown beech veneer, matte UV-cured clear coat | |
|---|---|---|
| Armrest dividers and end caps | Solid beech wood, 26mm thickness, rounded edge profile | |
| Internal support frame | 2mm thick cold-rolled steel square tube, electrostatic powder coated black | |
| Under-seat cubby dividers | 15mm hardwood plywood, veneer matched to seat panels | |
| Floor mounting hardware | Zinc-plated steel expansion bolts, hex socket drive | |
| Wood surface finish | Matte anti-scratch polyurethane clear coat, formaldehyde emission E0 grade |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Tiered elevation design | 3 stepped rows per seating block with 300mm riser per row, eliminating front-row sight line blockage | |
|---|---|---|
| Fixed floor mounting | Permanent anchoring to tiered concrete subfloor with steel hardware, no moving seat parts | |
| Open under-seat storage | 4 divided cubbies per bench, no enclosing doors, allows quick storage of attendee personal items | |
| Integrated armrest separation | Fixed armrests between each seat position, defines individual seating space and prevents cross-occupancy |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Courtroom public gallery seating | Formal reddish wood finish matches judicial space decor, tiered layout gives clear sight lines to proceedings | |
|---|---|---|
| Lecture hall and auditorium audience seating | Fixed tiered layout supports large audiences, under-seat storage holds student materials |
EU Market Access Requirements* EN Standards
| EN 12727:2000 | Furniture – Seating for public areas – Test methods for strength and durability | |
|---|---|---|
| EN 13761:2002 | Furniture – Auditorium seating – Functional and dimensional requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.11-2015 | Standard for seating for large public assembly venues, defines load and stability criteria |
|---|
Standards applicable to China-market projects
| GB/T 40263-2021 | General technical requirements for public assembly venue seating, applies to structural safety and performance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration and furnishing materials formaldehyde emission limits for wood furniture | |
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to panel construction and finish quality |
This product must meet the following technical requirements: 1. GB/T 40263-2021: General technical requirements for public assembly venue seating, applies to structural safety and performance; 2. GB 18584-2001: Indoor decoration and furnishing materials formaldehyde emission limits for wood furniture; 3. GB/T 3324-2017: General technical requirements for wooden furniture, applies to panel construction and finish quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
